1200 Nits Industrial Touchscreen Computer 32 Inch With 1920x1080 Resolution
32 Inch Industrial Touchscreen Computer With 16:9 Ratio
Industrial Touchscreen Computer Main Features
- Industrial grade level A LCD panel, sensitive and accurate PCAP touch technology
- High brightness 1200nits sunlight readable industrial touchscreen computer
- Configurations can be customized per customers’ requirements
- Industrial touch screen computer supports embedded, wall-mounted, rack-mounted, desktop, VESA mount
- UL, CE, RoHS, ISO, and CCC certificates are ready for global marketing use
Industrial Touchscreen Computer Specifications
| Complete Machine | ||
| Model No. | KOT-0315U-CA4P (P/N:KTP-320M-002-04) | |
| Series | All in one | |
| Display Type | 16:9 Ratio 31.5" TFT-LCD | |
| Active Area | 698.4*392.85 (mm) | |
| Monitor Dimensions (W*H*D) | 780*466*83 (mm) | |
| Suggested Resolution | 1920x1080 @ 60Hz | |
| Support Colors | 16.7M | |
| Brightness (Typ.) | Pure LCD Panel | 1200cd/m2 |
| With Touch Monitor | 1000cd/m2 | |
| Response Time (Typ.) | 8ms | |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 89°/89° |
| Vertical(up/down) | 89°/89° | |
| Contrast Ratio (Typ.) | 3000:1 | |
| Frequency (H/V) | 37.9～80KHz / 60～75Hz | |
| Power Supply |
Type: External brick Display voltage: DC 24V/ 5A Computer voltage: DC 12V/ 5A Input (line) voltage: 100-240 VAC, 50-60 Hz |
|
| Environment | Operating Temp. | -10～50°C |
| Operating RH | 20%～80% | |
| Storage Temp. | -20～60°C | |
| Storage RH | 10%～90% | |
| MTBF | ≥50,000 Hours | |
| LED Back Light Life (Typ.) | ≥50,000 Hours | |
| Mount Interface | Mount bracket, horizontal or vertical mount | |
| Agency approvals | CCC, ETL, FCC, CE, CB, RoHS | |
| Regular Warranty | 1 year | |
| Touch Screen | |
| Touch Type | 31.5" Capacitive touch screens |
| Touch input | USB |
| Response Time | ≤14ms |
| Hardness | 6H |
| Light Transmittance | ≥85% |
| Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
| Active Area | 705.00*397.85(mm) |
| Thickness | 4.3±0.2(mm) |
| Touch Test | ≥50,000,000 times |
| Input Voltage | DC 5V±5% |
The Industrial Touchscreen Computer Mechanical Dimensions
Our advantages
- Founded in 2006, KeeTouch is one of the leading manufacturers of touch products and suppliers of touch solutions.
- KeeTouch is focused on touch screen equipment such as open frame monitors, desktop monitors, touch computers, rugged industrial keyboards, and OEM products.
- 200+ employees, 100+ thousand manufacturing capacity per month, 70+ countries worldwide business.
- Regular items have large stock which can support fast shipment and help you catch the target market very quickly.
- Small trial orders and customized requirements are warmly welcome.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.
2. What’s your MOQ?
MOQ is 1 piece only.
3. Do you have branch offices in overseas markets?
Currently, we have branch offices in Germany, Russia, Brazil, and India.
4. What's your core advantage?
KeeTouch's core advantage is Customization service.
5. What are the shipping ways?
We will ship the goods according to the customer’s requirements. For sample, normally by FedEx, DHL, UPS, and TNT. For bulk orders, by air or by sea.
