Industrial 32 Inch Touch Screen Computer Monitor PCAP Multi Touch
32 Inch Industrial Touchscreen Computer Multi-Touch PCAP Touch Panel
Industrial Touchscreen Computer Main Features
- Sunlight readable 1000nits industrial touchscreen computer, Indoor/outdoor applications both workable
- Adopt industrial grade level A LCD panel, high resolution1920x1080,popular 16:9 ratio
- Various PC configurations like i3, i5, and i7. Storage can be 64G-1TB
- Supported different operating systems, for example, Windows, Linux, Raspberry Pi, etc
- RAM and SSD storage can be customized as per request
Industrial Touchscreen Computer Specifications
| KTP-320M-006 | ||
| Display | Screen | 32 inch |
| Resolution | 1920×1080 | |
| According to the proportion | 16:09 | |
| Brightness | 1000nit | |
| Contrast | 4000:1(Type)/3000:1(Min.) | |
| Response Time | 6.5ms | |
| View angle | 89/89/89/89 | |
| Active Display Area | 698.4x 392.85mm | |
| PC Configuration | CPU | Freescale i.MX6Q(4 core) |
| RAM | 2GB(default), Support DDR | |
| SSD | 8GB(default), EMMC flash | |
| Touch Screen | Touch Method | Capacitive Touch |
| Touch Surface Hardness | 6H | |
| Touch Screen Transparency | 85% | |
| I/O interface | 4-USB, 1-LAN, 1-HDMI, 1-COM1~5, 1-ON/OFF, 1-DC12V, 1-DC24V | |
| Other parameters | Cooling System | Fan |
| Enclosure Material | Metal | |
| Waterproof Rating | IP65 | |
| Power Consumption | ≤30W | |
| Working Temperature | 0 ~ 50 °C | |
| Storage Temperature | -20~60°C | |
| Storage Humidity | 20%~80% | |
| Storage Humidity | 10%~90% | |
| Size | 780*474*87.8 (mm) | |
| Warranty | 1 year | |
| Certification | CCC, ETL, FCC, CE, CB, RoHS | |
The Industrial Touchscreen Computer Mechanical Dimensions
Our advantages
- More than 16+ years of rich experience in producing and developing kinds of touch products.
- Main products include SAW/IR/PCAP touchscreen, touch monitor, touch computer, and other hardware accessories.
- Global certificates like UL, FCC, CE, ROHS, and TUV are all available.
- Strong R&D team with 40+ senior engineers to offer professional technical support and one-stop solutions.
- Aiming to build a worldwide sales network and comprehensive sales service system, any distributors' or agents' requests are welcomed.
FAQ
1. What is your delivery time?
3-5 work days for inventory items, 7-15 business days for bulk production.
2. What is your warranty period?
Our regular warranty is 12 months for all the products, with a 2-3 years Warranty (optional).
3. What package do you provide?
K-K layer carton box.
4. What are the shipping ways?
It all depends. For sample, normally by FedEx, DHL, UPS, and TNT. For bulk orders, by air or by sea.
5. Do you give any discount?
We will do our utmost to support you with a competitive price, also good service will be offered.
