Industrial LCD Touch Screen Monitor 10 Point Capacitive 21.5 Inch Size
Industrial 21.5 Inch High Brightness Outdoor Lcd Touch Screen Monitor 16:9 IP65
High Brightness Touch Monitor Main Features
1.HD Panel, Clear Presentation LED Backlight.
2.IP65 Front Panel Alluminum Alloy Enclouse.
3.Industrial Grade Rugged Design.
4.10-Point Capacitive Touchscreen.
5.Runs 24 Hours A Day.
6.Efficient Cooling System.
7.High And Low Temperature Resistant Design.
High Brightness Touch Monitor Specifications
| Complete Machine | ||
| Model No. | KOT-0215U-CA4PH (P/N:KOT-215P-028) | |
| Series | OT | |
| Display Type | 16:9 Ratio 21.5" TFT-LCD | |
| Active Area | 477.6*269.6(mm) | |
| Monitor Dimensions (W*H*D) | 535.1*327.1*56.4(mm) | |
| Suggested Resolution | 1920*1080 @ 60Hz | |
| Support Colors | 16.7M | |
| Brightness (Typ.) | Pure LCD Panel | 1500cd/m2 |
| With Touch Monitor | 1245cd/m2 | |
| Response Time (Typ.) | 5ms | |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 89°/89° |
| Vertical(up/down) | 89°/89° | |
| Contrast Ratio (Typ.) | 1000:1 | |
| Video Input | VGA/DVI/HDMI | |
| Frequency (H/V) | 40～90KHz / 50～75Hz | |
| Power Supply |
Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
|
| Environment | Operating Temp. | -15～50°C |
| Operating RH | 20%～80% | |
| Storage Temp. | -20～60°C | |
| Storage RH | 10%～90% | |
| MTBF | 30,000 Hours | |
| LED Back Light Life (Typ.) | 30,000 Hours | |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
| Agency approvals | CCC, ETL, FCC, CE, CB, RoHS | |
| Touch screen Type | 21.5”Projected Capacitive Touchscreen, | |
| Touch System Interface | USB(or Serial port,one point) | |
| Support System | 10 points in win7 | |
| Regular Warranty | 1 year | |
NOTE :
① The display SPEC. are adjusted according to the selected LCD screen and touch screen
② The support system is adjusted according the specific system and version.
High Brightness Touch Monitor Mechanical Dimensions
Applications
1. Public Places: subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums,convention centers, ticket agencies, HR market, lottery centers;
2. Business Organizations: supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
3. Financial Organizations: Banks, negotiable securities, funds, insurance companies, pawnshops;
4. Non-profit Organizations: Telecommunications, post offices, hospital, schools;
5. Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers.
FAQ
Q1. Are you a manufacturer?
A1:-Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.
Q2:Can I buy samples placing orders?
A2:-Yes.Please feel free to contactus.
Q3:What is your lead time?
A3:-It depends on the order quantity and the season you place the order.
-Usually we can ship within 7-15 days for small quantity,and about 30 days for large quantity.
Q4: What is your payment term?
A4: -T/T,Western Union,MoneyGram,and Paypal.This is negotiable.
Q5: What is the shipping method?
A5:-It could be shipped by sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX etc.).Please confirm with us before placing orders.
Q6: Do you support OEM/ODM?
A6: Yes we do.
