Waterproof PCAP Touch Monitor 43 Inch HD 1920x1080 With Metal Frame
KeeTouch 43 Inch PCAP Touch Screen Monitors Customized Metal Frame LCD Monitors
PCAP Touch Monitor Description
Our 43 inch PCAP touch monitors come with Full HD 1920x1080, full viewing angle 178°/178°, wide aspect ratio 16:9, exceptional color performance, high contrast, delivering excellent image clarity. Featuring metal frames with a UL 60950 ball-drop vandal proof, scratch-resistant, front panel waterproof, this display can be installed in the most demanding environment and build in different sets-up. They include VGA, HDMI, DVI for video input and USB for touch.
PCAP Touch Monitor Specifications
| Complete Machine | ||
| Model No. | KOT-0430U-CA4P(P/N:KOT-430P-004) | |
| Series | OT | |
| Display Type | 16:9 Ratio 43" TFT-LCD | |
| Active Area | 942.9*531.25 (mm) | |
| Monitor Dimensions (W*H*D) | 1004*592*64.6 (mm) | |
| Suggested Resolution | 1920x1080 @ 60Hz | |
| Support Colors | 16.7M | |
|
Brightness (Typ.) |
Pure LCD Panel | 380cd/m2 |
| With Touch Monitor | 320cd/m2 | |
| Response Time (Typ.) | 6.5 ms | |
|
Viewing Angle(Typ.at CR＞10)) |
Horizontal(left/right) | 89°/89° |
| Vertical(up/down) | 89°/89° | |
| Contrast Ratio (Typ.) | 3000:1 | |
| Video Input | VGADVIHDMI | |
| Frequency (H/V) | 30～80KHz / 60～75Hz | |
|
Power Supply |
Type: External brick Display voltage: DC 24V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
|
|
Environment |
Operating Temp. | -10～50°C |
| Operating RH | 20%～80% | |
| Storage Temp. | -20～60°C | |
| Storage RH | 10%～90% | |
| MTBF | 50,000 Hours | |
| LED Back Light Life (Typ.) | 50,000 Hours | |
|
OSD Control |
Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
| Agency approvals | CCC, ETL, FCC, CE, CB, RoHS | |
| Touch Type | 43" Capacitive touch screens, antiglare and tempered type | |
| Touch input | USB | |
| Support System | XP,WIN7,WIN8,WIN10,Linux,Android | |
| Regular Warranty | 1 year | |
NOTE :
① The display SPEC. are adjusted according to the selected LCD screen and touch screen
② The support system is adjusted according the specific system and version.
PCAP Touch Monitor Mechanical Dimensions
KeeTouch Advantages:
- Over 16 years' experience, Keetouch is a leading manufacturer of touch products and supplier of touch solution.
- Comprehensive product lines including PCAP/SAW/IR touch screen, Open frame touch monitors, all-in-one touch panel PCs, sheet metal cases.
- Monthly capacity is more than 30,000 pcs
- Based your needs, product design, logo and function including anti-glare, privacy film, brightness, hardware and software can be customized.
-
Established branches office all over the world, such as Germany, Russia, Brazil, india, etc, to provide local service.
-
Our products are certified with CE, UL, CB, BIS, ISO 14001, ISO 9001. etc. they are all go through strict and comprehensive quality management system test, which enable us to control every production aspect and ensure the reliable and good performance of products from the very beginning to the finished process.
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Do you give any discount?
We will do utmost to support you with the competitive price, also good service will be offered.
2. What’s your MOQ for the PCAP touch monitor?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the PCAP touch monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk production.
5. . What are the shipping ways?
We will ship the goods according to customer’s requirement. For sample, normally by FedEx, DHL, UPS, TNT. For bulk order, by air or by sea.
