1024x768 Resolution PCAP 15 Inch Touch Monitor For Kiosks
15 Inch PCAP Touch Monitor 1024x768 Resolution For Kiosks
PCAP Touch Monitor Main Features
- With PCAP touch technology, up to 10 points touch with great touch experience
- High resolution and high contrast support high quality image
- Anti-vandal and dust-proof PCAP touch monitor
- VGA&DVI interfaces, USB port for touch
- Multiple mounting options include VESA mount, horizontal and vertical brackets mount
- Operation system: XP, WIN7, WIN8, WIN10, Linux, Android
- Other sizes (7’’- 43’’) can be offered.
PCAP Touch Monitor Specifications
| Complete Machine | ||
| Model No. | KOT-0150U-SA4BW(P/N:KOT-150P-017-02) | |
| Series | OT | |
| Display Type | 4:3 Ratio15"TFT-LCD, LEDbacklight | |
| Active Area | 304.1x 228.1(mm) | |
| Monitor Dimensions (W*H*D) | 398*268*56.3(mm) | |
| Suggested Resolution | 1024*768 @ 60Hz | |
| Support Colors | 16.2M | |
| Brightness (Typ.) | Pure LCD Panel | 400cd/m2 |
| With Touch Monitor | 190cd/m2 | |
| Response Time (Typ.) | 6ms | |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right): 80°/80° | |
| Vertical(up/down): 65°/80° | ||
| Contrast Ratio (Typ.) | 450(Min.), 800(Typ.) | |
| Video Input | VGA/DVI | |
| Frequency (H/V) | 30～80KHz / 60～75Hz | |
|
Power Supply |
Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 V/AC, 50-60 Hz |
|
|
Environment |
Operating Temp. | 0～50°C |
| Operating RH | 20%～80% | |
| Storage Temp. | -20～60°C | |
| Storage RH | 10%～90% | |
| MTBF | ≥30,000 hours | |
| LED Back Light Life (Typ.) | ≥30,000 hours | |
| Weight(N.W/G.W) | 3.3Kg(1 pcs) / 7.75Kg(2pcs in one package) | |
| Package dimensions | 445*200*390(mm)(2pcs in one package) | |
| Power Consumption | Standby Power: ≤1.5W Operating Power: ≤10.3W | |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
| Agency approvals | UL, FCC, CE, CB, RoHS | |
| Regular Warranty | 1 year | |
| Touch Screen | |
| Touch Type | 15" Capacitive touch screens |
| Touch input | USB |
| Response Time | ≤8ms |
| Hardness | 6H |
| Light Transmittance | ≥85% |
| Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
| Active Area | (305±0.3)x (229±0.3)(mm) |
| Thickness | 4±0.25(mm) |
| Touch Test | ≥50,000,000 times |
| Input Voltage | DC 5V±5% |
NOTE :
① The display SPEC. are adjusted according to the selected LCD screen and touch screen
② The support system is adjusted according the specific system and version.
PCAP Touch Monitor Mechanical Dimensions
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.
2. What’s your MOQ for the PCAP Touch Monitor?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the PCAP Touch Monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. Can you produce the PCAP Touch Monitor according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.
