CCC Approved 19 Inch SAW Touch Monitor IP65 Waterproof For Kiosks
19 Inch SAW Touch Monitor IP65 Waterproof For Kiosks
Description of SAW Touch Monitor
This SAW touch monitor has main features as below: 5:4 display type, 1280*1024 high resolution, 1000:1 high contrast ratio. Moreover, with our professional R&D team, customized services can be offered per customer’s individual requirements. And other sizes can be offered or customized (7’’- 43’’).
Specification of SAW Touch Monitor
| Complete Machine | ||
| Model No. | KOT-0190US-SA4BCW (P/N:KOT-190C-013) | |
| Series | OT | |
| Display Type | 5:4 Ratio 19" TFT-LCD | |
| Active Area | 376.32*301.06 (mm) | |
| Monitor Dimensions (W*H*D) | 416*344*54(mm) | |
| Suggested Resolution | 1280x1024 @ 60Hz | |
| Support Colors | 16.7M | |
| Response Time (Typ.) | 5ms | |
| Contrast Ratio (Typ.) | 1000:1 | |
| Video Input | VGA/DVI | |
| Frequency (H/V) | 37.9 -80KHz/ 60～75Hz | |
| Power Supply |
Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
|
| Environment | Operating Temp. | 0～50°C |
| Operating RH | 20%～80% | |
| Storage Temp. | -20～60°C | |
| Storage RH | 10%～90% | |
| MTBF | ≥50,000 Hours | |
| LED Back Light Life (Typ.) | ≥50,000 Hours | |
| Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤20W | |
| Mount Interface |
1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount |
|
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
| Regular Warranty | 1 year | |
| Touch Screen | |
| Touch Type | 19" Surface acoustic wave touch screen |
| Touch input | USB/RS232 |
| Response Time | ≤8ms(USB) ; ≤12ms(RS232) |
| Hardness | 7H |
| Light Transmittance | ≥90% |
| Active Area | 382*305(mm) |
| Thickness | 4±0.1(mm) |
| Touch Test | ≥50,000,000 times |
| Input Voltage | DC 5V±5% |
SAW Touch Monitor Mechanical Dimensions
Applications
- Retail
- Gaming
- Kiosk
- self-service
- Finance
- Transit
- Conference
- Education
- Healthcare
- public service
- e-commerce
- Hotels
- restaurants
Our Advantages:
- Comply with ISO9001 quality system,ISO14001 environment management system and OC080000 limit harmful material management system certifications
- 30,000+ manufacturing capacity per year
-
Efficient Warehousing and Logistics
-
Branch offices widely spreads all over the world,such as Russia,Brazil,Germany and India
-
Developing a large number of agents and distributors,offering world-wide sales networks and comprehensive after-sale service system
Advantages of SAW Touch Monitor
1. High Clarity: industrial touch monitors maintain high clarity and contrast levels, even when viewed from different angles or under varying lighting conditions, providing a clear and vibrant display.
2. High Sensitivity: 24 touch screen monitor are highly sensitive and can detect even the slightest touch or gesture, providing a responsive and accurate user experience.
3. Durability: 15 touch screen monitor are highly durable and can withstand heavy usage, making them ideal for use in public places such as retail stores, museums, and airports.
