Vandal Proof 19'' IR Touch Monitor Waterproof For Kiosks OEM ODM
19'' IR Touch Monitor Waterproof Vandal-proof for Kiosks
Description of IR Touch Monitor
This USB touch screen monitor has main features as below: 5:4 ratio display type, 1280*1024 resolution, 1000:1 high contrast ratio, along with wide viewing angle. This industrial touch monitor comes with supper image quality. Also, with our professional R&D team, OEM and ODM services can be offered according to customer’s requirements. And other sizes can be offered or customized (7’’- 43’’).
Infrared Touch Monitor Specifications
| Complete Machine | ||
| Model No. | KOT-190C-025 | |
| Series | OT | |
| Display Type | 5:4 Ratio 19" TFT-LCD | |
| Active Area | 376.32*301.06(mm) | |
| Monitor Dimensions (W*H*D) | 420*345*52.5(mm) | |
| Suggested Resolution | 1280x1024 @ 60Hz | |
| Support Colors | 16.7M | |
| Response Time (Typ.) | 5ms | |
| Contrast Ratio (Typ.) | 1000:1 | |
| Video Input | VGA | |
| Frequency (H/V) | 37.9 -80KHz/ 60～75Hz | |
| Power Supply |
Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
|
| Environment | Operating Temp. | 0～50°C |
| Operating RH | 20%～80% | |
| Storage Temp. | -20～60°C | |
| Storage RH | 10%～90% | |
| MTBF | ≥50,000 Hours | |
| LED Back Light Life (Typ.) | ≥50,000 Hours | |
| Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤20W | |
| Mount Interface |
1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount |
|
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
| Regular Warranty | 1 year | |
| Touch Screen | |
| Touch Type | 19"Infrared touch screen |
| Touch input | USB |
| Response Time | ≤32ms |
| Hardness | 7H |
| Light Transmittance | ≥90% |
| Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
| Active Area | 378*303(mm) |
| Thickness | 9±1(mm) |
| Touch Test | ≥50,000,000 times |
| Input Voltage | DC 5V±5% |
Infrared Touch Monitor Mechanical Dimensions
Rugged touch screen monitor Applications
- Retail
- Gaming
- Kiosk
- self-service
- Finance
- Transit
- Conference
- Education
- Healthcare
- public service
- e-commerce
- Hotels
- restaurants
Advantages of IR Touch Monitor
1. High durability: lcd touch monitors are designed to withstand heavy usage and can handle millions of touch inputs. They are resistant to scratches, dust, and water, making them ideal for use in high-traffic areas.
2. High accuracy: android advertising display offer a high level of accuracy when it comes to touch input detection. This makes them suitable for applications that require precise touch inputs, such as drawing and design software.
3. Multi-touch support: ir frame touch screen can detect multiple touch inputs simultaneously, allowing for multi-touch gestures such as pinch-to-zoom and two-finger scrolling.
Service:
1. Warranty: One year .
2. After-sales Service: For the user questions or machine fault,we will arrange engineer provide remote-control technical support and maintenance services for you at any time.
3. Product Quality Assurance: Our products had gone through authoritative evaluation, approves CE, RoHS certification, and strict test before shipment.
4. After-sales Service Team: The after-sales service center is equipped with a professional technical service team with abundant experience in maintenance and support.
FAQ:
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.
2. What’s your MOQ for the 10 point touch screen?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the IR Touch Monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
