OEM And ODM PCAP Touch Screen Computer 15 Inch TFT LCD Display
15 Inch Industrial Touchscreen Computer 5:4 Ratio PCAP Touch Screen
Description of Industrial Touchscreen Computer
This industrial touchscreen computer comes with main features as below: PCAP touch screen, 1024*768 resolution, 700:1 contrast ratio with wide viewing angle. This industrial touchscreen computer provides various configurations optional, J1900, I3, I5. Besides, with over 40 R&D engineers, OEM and ODM are welcomed. And other sizes (7’’-43’’) can be offered or customized
Specification of Industrial Touchscreen Computer
| Complete Machine | ||
| Model No. | KOT-0150U-CA4P (P/N:KTP-150M-002-02) | |
| Series | All-in-One Touch Computer | |
| Display Type | 5:4 Ratio 15" TFT-LCD | |
| Active Area | 304.1*228.1 (mm) | |
| Monitor Dimensions (W*H*D) | 360.5*292*72 (mm) | |
| Suggested Resolution | 1024*768 @ 60Hz | |
| Support Colors | 16.2M | |
| Brightness (Typ.) | Pure LCD Panel | 300cd/m2 |
| With Touch Monitor | 255cd/m2 | |
| Response Time (Typ.) | 25ms | |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 80°/80° |
| Vertical(up/down) | 70°/70° | |
| Contrast Ratio (Typ.) | 700:1 | |
| Frequency (H/V) | 37.9～80KHz / 60～75Hz | |
| Power Supply |
Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
|
| Environment | Operating Temp. | 0～50°C |
| Operating RH | 20%～80% | |
| Storage Temp. | -20～60°C | |
| Storage RH | 10%～90% | |
| MTBF | ≥30,000 Hours | |
| LED Back Light Life (Typ.) | ≥30,000 Hours | |
| Mount Interface |
1.VESA 75mm and 100mm 2. Mount bracket, horizontal or vertical mount |
|
| Touch Screen | |
| Touch Type | 15" Capacitive touch screens |
| Touch input | USB |
| Response Time | ≤8ms |
| Hardness | 6H |
| Light Transmittance | ≥85% |
| Support System | Android/windows(optional) |
| Active Area | 305.1*229.1 (mm) |
| Thickness | 4.3±0.2 (mm) |
| Touch Test | ≥50,000,000 times |
| Input Voltage | DC 5V±5% |
Industrial Touchscreen Computer Mechanical Dimensions
Applications
- Automatic system: intelligent self-service terminal, intelligent retail terminal, O2O smart device, robot equipment, Industrial control equipment, Advertising kiosks, All-in-one conference machine, etc.
- Public Places: subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers;
- Financial Organizations: Banks, negotiable securities, funds, insurance companies, pawnshops; · Non-profit Organizations: Telecommunications, post offices, hospitals, schools;
- Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers.
Advantages of PCAP Industrial Touchscreen Computer
1. Durability: industrial touchscreen computer price are designed to withstand harsh environments such as extreme temperatures, humidity, and dust. They are also resistant to scratches, impacts, and other physical damage.
2. Accurate and responsive touch control: PCAP touchscreen technology allows for accurate and precise touch control, even with gloves or other protective gear. The touch response is also fast and smooth, providing a better user experience.
3. Multitouch capability: PCAP touchscreens support multitouch gestures such as pinch-to-zoom and swipe, making them more intuitive and user-friendly.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.
2. What’s your MOQ for the Industrial Touchscreen Computer?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the Industrial Touchscreen Computer?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
