Dustproof 1440x900 Resolution 19 Inch IR Touch Monitor For Outdoors
19 Inch IR Touch Monitor 1440x900 Resolution for Outdoors
Description of Infrared Touch Screen Monitor
IR touch monitors delivers high durability, high accuracy, and multi-touch functions. This 19 inch IR touch monitor is super durable, which can withstand harsh environments. It is a great choice for indoor and outdoor applications. In addition, with our professional R&D engineers, customized services can be offered to meet customer’s different kinds of requirements.
IR Touch Screen Technology Specifications
| Complete Machine | |||
| Model No. | KOT-190G-022(P/N:KOT-190P-029) | ||
| Series | Open frame monitor | ||
| Structure | metal frame, dustproof,open frame,black dustproof metal frame | ||
| Display Type | 19＂Ratio:16:10,Active matrix TFT-LCD,LED backing | ||
| Active Area | 16.1＂(408.24mm)×10.0＂(255.15mm) | ||
| Suggested Resolution | 1440×900 | ||
| Support Colors | 16.7M | ||
| Brightness (Typ.) | Pure LCD Panel | 250cd/m2 | |
| Response Time (Typ.) |
5ms |
||
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 85°/85° | |
| Vertical(up/down) | 80°/80° | ||
| Contrast Ratio (Typ.) | 1000:1 | ||
| Input | H/V Separate Sync. (TTL) | ||
| Video Input | Mini D-Sub 15-pin VGA | ||
| Frequency (H/V) | 30～80KHz / 60～75Hz | ||
| Power Supply |
Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 50-60 Hz |
||
| MTBF | 30,000 Hour | ||
| Mounting Type |
Standard:VESA 75mm and 100mm Optional:Mount bracket, horizontal or vertical mount |
||
| OSD Control | Buttons | AUTO,+,POWER,-,MENU | |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | ||
Infrared Touch Panel Mechanical Dimensions
Infrared Touch Monitor Applications
IR Touch Monitor are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
Why choose us?
1. Quality products: All our products have passed strict quality inspection by the quality department before shipment.
2. Competitive pricing: With a strong supply chain, our products’ prices are very competitive.
3. Timely delivery: We have raw materials in stock all year round, the goods can be produced and sent out quickly.
4. Responsive Customer Service: Professional after-sales team at any time to provide services to customers.
FAQ:
1. What package do you provide for the IR Touch Monitor?
Our package usually is carton.
2. Do you have stock?
Yes, we have a large quantity of stock for our regular model products.
3. What are the shipping ways?
We will ship the goods according to customer’s requirement. For sample, normally by FedEx, DHL, UPS, TNT. For bulk order, by air or by sea.
4. Do you give any discount for the IR Touch Monitor?
We will do utmost to support you with the competitive price, also good service will be offered.
