19 Inch 1280x1024 Capacitive Touch Screen Monitor With Electromagnetic Screen And Stylus
19 Inch PCAP Touch Monitor 1280x1024 with Electromagnetic Screen and Stylus
Description of PCAP Touch Monitor
- PCAP multi-touch screen, come with electromagnetic screen and stylus
- Dust-proof and vandal-proof, scratch resistant PCAP touch monitor
- High contrast ratio and high resolution with high definition visual enjoyment
- High-quality PCAP touch monitor, lasting touch, durable even in harsh environment
- VGA/DVI interfaces,USB for touch input
- Multiple mounting options include VESA mount, horizontal vertical brackets mount
- Support system: XP, WIN7, WIN8
- Other sizes are optional (7’’-43’’)
Specification of PCAP Touch Monitor
| Model No. |
KOT-0190U-CA4P (KOT-190P-058) |
|||
| Series | OT , With electromagnetic Screen | |||
| Display Type | 5:4 Ratio | |||
| Display Active Area | 377.3mm×302.1mm | |||
| Support Colors | 16.7M | |||
|
Brightness(Typ.) |
Pure LCD Panel | 350cd/m2 | ||
| With Projected Capacitive Touchscreen | 182cd/m2 | |||
| Display Response Time(Typ.) | 25ms | |||
|
Viewing Angle(Typ.at CR>10) |
Horizontal(left/right) | 80°/80° | ||
| Contrast Ratio(Typ.) | 800:1 | |||
| Video Input | VGA and DVI | |||
| Frequency(H/V) | 30～80KHz / 60～75Hz | |||
| Power Supply |
Type: External brick Input (line) voltage: 100-240 VAC, 47-63 Hz |
|||
|
Environment |
Operating Temp. | 0～50°C | ||
| Storage Temp. | -10～60°C | |||
| Operating RH | 20%～80% | |||
| Storage RH | 10%～90% | |||
| MTBF | 30,000 Hours | |||
|
OSD Control |
Buttons | AUTO,+,POWER,-,MENU | ||
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |||
| Agency Approval |
CCC,UL,FCC,CE,CB,RoHS |
|||
|
Touch input |
USB |
|||
| Regular Warranty | 1 Year | |||
Application:
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ:
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over 17 years, located in Shenzhen, China.
2. What’s your MOQ for the PCAP Touch Monitor?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the PCAP Touch Monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. Can you produce the PCAP Touch Monitor according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.
5. What is your payment method?
We can accept T/T, Western Union, e-Checking and Alipay. ( L/C can be negotiable. )
6. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk production.
