Dust Proof Vandal Proof PCAP Touch Monitor Scratch Resistant
Price:
Negotiable
MOQ:
one piece
Delivery Time:
7-15 work days
Brand:
KeeTouch
Product Description
Product Description:
PCAP Touch Monitor: Multi-Touch Interactive Display with 9.7" Capacitive Touch Screen
PCAP Touch Monitor is a multi-touch interactive display with a 9.7" projected capacitive touch screen. Its suggested resolution is 1024*768. It is a riot-proof capacitive touch screen display that supports both VGA and DVI video inputs. The touch interface is connected with USB. This touch monitor is ideal for interactive display and multi-touch applications.The 7"- 43" are optional.
Specification:
| Complete Machine | ||||
| Model No. | KOT-097P-003 | |||
| Type | OT | |||
| Display Type | 4:3 Ratio 9.7＂TFT-LCD, LED backlight | |||
| Active Area | 196.6 x 147.46mm | |||
| Monitor Dimensions (W*H*D) | 259*215*38.8(mm) | |||
| Suggested Resolution | 1024*768 | |||
| Support Colors | 16.7M | |||
| Brightness (Typ.) | Pure LCD Panel | 300cd/m²(Typ.)/220cd/m²(Min.) | ||
| With Touch Monitor | 238cd/m²(Typ.)/167cd/m²(Min.) | |||
| Response Time (Typ.) | 20ms | |||
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 70 °/70 °(Typ.)/ 60 °/70 °(Min.) | ||
| Vertical(up/down) | 80 °/80 °(Typ.)/70 °/80 °(Min.) | |||
| Contrast Ratio (Typ.) | 500:1(Typ.)/400:1(Min.) | |||
| Video Input | VGA/DVI | |||
| Frequency (H/V) | 43.86～60KHz / 60～75Hz | |||
Power Supply | Type: External brick | |||
Environment | Operating Temp. | 0～50°C | ||
| Operating RH | 20%～80% | |||
| Storage Temp. | -20～60°C | |||
| Storage RH | 10%～90% | |||
| MTBF | ≥ 10,000 hours | |||
| LED Back Light Life (Typ.) | ≥ 10,000 hours | |||
| Weight(N.W/G.W) | 2Kg(1pcs)/4.5Kg(2pcs in one package) | |||
| Package dimensions | 259.38*215.48*39.66(mm)(2pcs in one package) | |||
| Power Consumption | Standby Power: ≤1.5W Operating Power: ≤12W | |||
| Mount Interface | 1. VESA 75mm 2.Mount bracket, horizontal or vertical mount | |||
| OSD Control | Buttons | Confirm, MENU, AUTO, Up, Down, Power | ||
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |||
| Touch Screen | |
| Touch Type | 9.7 inch Projected Capacitive Riot-proof Touch Screen |
| Touch input | USB |
| Response Time | ≤15ms |
| Touch Screen Resolution | 16384*9600 |
| Hardness | 6H |
| Riot Test | Meets 130g Steel Ball, 50cm Drop Experiment |
| Support System | WIN7,WIN8,WIN10 support 10 points, XP support single point |
| Active Area | 197.6*148.5(mm) |
| Thickness | 1.85±0.2(mm) |
| Touch Test | ≥ 50,000,000 times |
| Input Voltage | DC 5V±5% |
Applications:
PCAP Touch Monitor are widely used in retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
Q&A for this PCAP Touch Monitor
- Q:What certifications does this PCAP Touch Monitor have?
A:this PCAP Touch Monitor has certifications of CCC, UL, FCC, CE, CB, and RoHS. - Q:Where is this PCAP Touch Monitor manufactured?
A:this PCAP Touch Monitorr is manufactured in ShenZhen, China. - Q:What is the minimum order quantity for this PCAP Touch Monitor?
A:The minimum order quantity for this PCAP Touch Monitor is one piece. - Q:What is the price for this PCAP Touch Monitor?
A:The price for this PCAP Touch Monitor is negotiable. - Q:What are the payment terms for this PCAP Touch Monitor?
A:The payment terms for this PCAP Touch Monitor is T/T, Western Union, and L/C.
