21.5 Inch PCAP Touch Monitor 1000:1 Contrast Ratio VGA\DVI For Self-Service Kiosks
Product Description:
21.5 Inch PCAP Touch Monitor 1000:1 Contrast Ratio VGADVI For Self-Service Kiosks
The PCAP Touch Monitor is a multi-touch interactive display for a variety of applications. This 21.5" capacitive touch screen offers a beautiful LED back light display with 1000:1 contrast ratio and 1920x1080 resolution. The LED back light life is 30,000 hours, and the touch test is ≥50,000,000 times, making it a dependable and durable option. The capacitive touch screen of the PCAP Touch Monitor allows for precise, smooth, and accurate multi-touch operations, perfect for gaming, office work, digital signage, and more.
Specification:
| Complete Machine | ||
| Model No. | KOT-0215U-CA4P (P/N:KOT-215P-014) | |
| Series | OT | |
| Display Type | 16:9 Ratio 21.5" TFT-LCD | |
| Active Area | 476.6*269 (mm) | |
| Monitor Dimensions (W*H*D) | 512.1*307.3*47(mm) | |
| Suggested Resolution | 1920*1080 @ 60Hz | |
| Support Colors | 16.7M | |
| Brightness (Typ.) | Pure LCD Panel | 250cd/m2 |
| With Touch Monitor and Peep-proof protection film | 127cd/m2 | |
| Response Time (Typ.) | 5ms | |
| Viewing Angle(Typ.at CR>10)) | Horizontal(left/right) | 85°/85° |
| Vertical(up/down) | 80°/80° | |
| Video Input | VGADVI | |
| Power Supply | Type: External brick Display voltage: DC 12V±5% | |
| Environment | Operating Temp. | 0~50°C |
| Operating RH | 20%~80% | |
| Storage Temp. | -20~60°C | |
| Storage RH | 10%~90% | |
| Weight(N.W/G.W) | 5.6Kg(1pcs)/13.4Kg(2pcs in one package) | |
| Package dimensions | 605*400*195(mm)(2pcs in one package) | |
| Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤30W | |
| Touch Screen | |
| Touch Type | 21.5" Capacitive touch screens |
| Touch input | USB |
| Response Time | ≤10ms |
| Hardness | 6H |
| Light Transmittance | ≥85% |
| Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
| Active Area | 479.04*270.51(mm) |
| Thickness | 4.3±0.3(mm) |
| Touch Test | ≥50,000,000 times |
| Input Voltage | DC 5V±5% |
Applications:

Support and Services:
PCAP Touch Monitor Technical Support and Services
- Comprehensive technical support and troubleshooting assistance
- Upgrades and updates for the latest products and features
- Onsite installation and setup
- Warranty and repair services
- Custom programming and development
- Remote monitoring and support
Packing and Shipping:
PCAP Touch Monitor packaging and shipping requires special care to ensure the safety of the product. Here are some guidelines to follow when packing and shipping PCAP Touch Monitors:
- Use a box that is large enough to fit the monitor with at least 2 inches of packing material surrounding it.
- Securely tape all openings, flaps and seams of the box.
- Place the monitor in the center of the box with the screen facing up.
- Fill in all empty space with packing material such as bubble wrap or packing peanuts.
- Label the box with the appropriate shipping information.
- Drop off the package at your local shipping facility.
