Z9 Tighten Conveyor Coupling Sleeve Stainless Steel

Belt Conveyor Accessories Z9 Tighten The Coupling Sleeve Stainless Steel

The characteristics of the expansion sleeve

1. The use of expansion sleeve makes the manufacture and installation of host parts simple. The machining of the shaft and hole for installing the expansion sleeve does not require the same high manufacturing tolerances as the interference fit. When INSTALLING THE expansion sleeve, THERE is no need to heat, cool or pressurize the equipment, just tighten the bolt according to the required torque. And easy to adjust. The hub can be easily adjusted to the desired position on the shaft. Expansion sleeves can also be used to join poorly soldered parts.

2. Long service life and high strength. Expansion sleeve depends on friction rotation, there is no keyway to be connected to weaken, there is no relative movement, the work will not produce wear.

3. Expansion sleeve in overload, will lose the connection, can protect the equipment from damage.

4. Expansion sleeve connection can bear multiple loads, its structure can be made into a variety of patterns. According to the size of the installation load, you can also use multiple expansion sleeve in series.

5. The expansion sleeve is easy to disassemble and has good interchangeability. Since the expansion sleeve can combine the hub of the shaft with larger clearance, the bolt can be tightened when disassembling, so that the connected part can be easily disassembled. When the contact surface is tight and easy to fit without rust, it is also easy to disassemble.
