Red Belt Conveyor Accessories Explosion Proof Two Way Conveyor Belt Switch

Belt Conveyor Accessories Red Explosion-Proof Two-Way Drawstring Switch

Two-way pull cord switch HFKLT2-2 Two-way pull cord switch KLT2-2 is commonly known as emergency stop switch. Acting on the belt conveyor site need to stop, through the switch action to stop the conveyor. Two-way stretching wire switch used in steel, cement plants, power plants, mining with belt conveyor such as factories and mines, on both sides of the product is installed on belt conveyor, is a kind of protection to the belt conveyor emergency switch, the switch operating range any pull rope, cut off the circuit operation makes all downtime, realize the tape machine and personal safety protection, it break up move and automatic, Manual operation after self-pin, and a warning sign, must be manually reset. Automatic type automatic reset, when the emergency happens any pull rope sensing gas can stop.

Basic parameters of pull rope switch:

Protection level IP67

Shell material aluminum alloy surface seiko paint

Transmission rod material stainless steel

Cable tension required 49±10N(5±1kgf)

Pick up points 2

Contact capacity 220V/ 250V /380V/480V/AC 3A/5A

Wiring port 6~12mm cable

Applicable temperature -20℃~+60℃

The service life is 500,000 times

Installation of two-way drawstring switch

This product is generally installed on the two-line frame along the belt conveyor. Please refer to Figure 3 for details.

1. Secure the pull cable switch to the support.

2. The distance between the two machines is 25~30m, with a diameter of 4mm wire rope connection, the tightness should be appropriate.

3. In order to reduce the misoperation caused by the influence of the dead weight of the wire rope on the switch, a supporting ring is welded to the frame every 3m to support the wire rope and ensure that it can work normally.
