YDC650 65-600T Multi PC Strand Electric Hydraulic Jack For Bridge Building Prestressing Hydraulic Electric Jack
Features of Hydraulic stressing jackLarge tonnage jack 65-600 tons; Bridge hollow steel strand Jack
Main parts of the jack is made of high strength steelhas the advantages of compact structure, light weightsmall size and characteristics
Short axial length, steel wire tension for short lengthcan save steel material.
Lifting and flexible, durableeasy operation and convenient maintenance
Introducing our Multi PC Strand Electric Hydraulic Jack for Bridge Building Prestressing. This hydraulic jack is designed for large tonnage applications, ranging from 65 to 600 tons, making it ideal for bridge construction and prestressing. The main parts of this jack are made of high strength steel, providing the advantages of compact structure, light weight, and small size. Its short axial length allows for steel wire tension over a shorter length, resulting in significant steel material savings. With its lifting and flexible capabilities, this hydraulic jack is not only durable but also easy to operate and maintain.
| Model specifications | Nominal tensile force (KN) | Nominal oil pressure (Mpa) | Through-hole diameter (mm) | Install limit plate aperture (mm) | Mounting tool (mm) | Outside diameter size (mm) Diameter * Height |
| YDC650 | 650 | 48 | 72 | 99 | 95 | 200*385 |
| YDC1000 | 1000 | 50 | 78 | 111 | 111 | 230*385 |
| YDC1500 | 1500 | 52 | 94 | 150 | 150 | 270*390 |
| YDC2000 | 2000 | 53 | 118 | 177 | 177 | 320*400 |
| YDC2500 | 2500 | 52 | 128 | 210 | 185 | 345*400 |
| YDC3000 | 3000 | 52 | 135 | 190 | 185 | 370*400 |
| YDC3500 | 3500 | 51 | 160 | 232 | 232 | 420*400 |
| YDC4000 | 4000 | 52 | 165 | 252 | 252 | 450*410 |
| YDC5000 | 5000 | 52 | 196 | 260 | 265 | 500*410 |
| YDC6500 | 6500 | 53 | 220 | 295 | 235 | 580*420 |
| YDC10000 | 10000 | 50 | 270 | 440 | 415 | 740*570 |
Q1: Are you a factory or trade company?
A1: We are a factory. And we have ourselves trading company.
Q2: What is the exact address of your factory?
A2: No.27, Beichen Village Industrial Park, Weiyang District, Shaanxi Province China.
Q3: Warranty terms of your machine?
A3: One-year warranty for the machine and technical support according to your needs.
Q4: Will you provide some spare parts for the machines?
A4: Yes, of course.
Q5: What about the voltage of products? Can they be customized?
A5: Our standard voltage is 380V, 50HZ, and 3phase. The voltage can be customized according to your equipment.
Q6: Which payment term can you accept?
A6: 100% T/T( Decide according to actual situation)
Q7: How long will it take to arrange production?
A7: we can deliver the normal goods within 7-15 days. Other nonstandard electrical items we will deliver within 25-30 days.
Q8: Can you accept OEM orders?
A8: Yes, with a professional design team, OEM orders are highly welcome.
Q9: Which trade term can you accept?
A9: Available trade terms: FOB, CIF, CFR, EXW, etc.
Q10: Do you provide samples? Is it free or extra?
A10: Yes, we could offer you the sample machine. But it's not free. You need to pay for the sample and the cost of the freight.
Q11: What are your terms of payment?
A11: We accept T/T, Western Union, Money Gram, Paypal, L/C, etc.
Why you choose us:
1. We are a real factory offering products and providing free technical advice.
2. Company in business for many years and served Over 50 countries' customers.
3. All machines with CE, ISO, and SGS certificates. Machine and spindle warranty 1 year.
4. We have phone support in English, if you have any questions, you can call us, and we can give you the best solution within 24 hours.
5. Fast delivery, save your time.
