High Efficiency Aluminum Alloy Solar Panels Photovoltaic Panels Stable Performance
Solar panels, also known as photovoltaic (PV) panels, their main role is to convert light energy into electricity. Light energy is a renewable and sustainable energy source. It is used to power household or commercial equipment. This would reduce dependence on fossil fuels and reduce carbon emissions.
Solar panels, which consist of multiple solar cells, are usually made of silicon.
When sunlight hits a solar cell, it excites electrons in the silicon atoms, which creates an electric current. This direct current (DC) can be converted into alternating current (AC) by an inverter.
1. Silicon Solar Cells
2. The battery material consists of inorganic salts such as gallium arsenide III-V compound, cadmium sulfide, copper indium selenium, and other multi-compounds.
3. Solar cells made from functional polymer materials.
4. Nanocrystalline solar cells.
Weight:30KG
Dimensions:2464mm*1134mm*35mm
Cell Amount:782 pcs
Maximum System Voltage:1500V
Junction Box:IP68
Frame:Aluminum Alloy
Cable:4mm2/400mm
Connector:MC4 Compatible
Application Level:Class A
| Module Type | JMD580P156M | JMD585P-156M | JMD590P-156M | JMD595P-156M | JMD600P-156M |
| Maximum Power (Pmax/W) | 580 | 585 | 590 | 595 | 600 |
| Open Circuit Voltage(Voc/V) | 53.50 | 53.65 | 53.80 | 53.95 | 54.10 |
| Short Circuit Current | 13.82 | 13.89 | 13.96 | 14.03 | 14.10 |
| Maximun Power Voltage(Vmp/V) | 44.90 | 45.07 | 45.22 | 45.39 | 45.53 |
| Maximum Power Current(lmp/A) | 12.92 | 12.98 | 13.05 | 13.11 | 13.18 |
| Module Efficiency(%) | 20.70 | 20.90 | 20.10 | 21.30 | 21.50 |
