Ultrasonic Automatic Food Cosmetic Cream Paste Plastic Tube Filling Sealing Machine
Ultrasonic Automatic Food Cosmetic Cream Paste Plastic Tube Filling Sealing Machine
Simple Introduction:
Tube Filling Sealing Machine is a high-tech product which successfully developed and designed by adopting
advanced technology from abroad and strictly meet GMP requirement. PLC controller and color
touch screen are applied and made it possible for programmable control of the machine. It can
perform the filling for ointment, cream jellies or viscosity material, sealing or tail folding, batch
number embossing (include manufacture date) automatically. It's ideal equipment for aluminum
tube filling and sealing for cosmetic, pharmacy, foodstuff and bond industries.
| Product Name | Tube Filling and Sealing Machine WD400 | Tube Filling and Sealing Machine WD400-A |
| Power Supply | 50Hz/380V 3P | |
| Main Motor | 1.1KW | |
| Jacket Barrel Heating Power | 2 KW | |
| Operation Speed | 30-50/min/max | |
| Filling Range | Plastic Tube,5-250ml | Aluminum Tube,5-150ml |
| Suitable Tube Length | 50-210mm(can be customized) | 50-180mm |
| Suitable Tube Diameter | 13-50mm | 13-50mm |
| Whole Machine(L×W×H) | 1950×1000×1800mm | |
| Weight | (about)850Kg | |
Washing Part
1. Into bottle way is air conveyor direct connection with Bottle dial .
2. All 304/316 stainless steel rinse heads, water spray style inject design, more save water consumption and more clean .
3. 304/316 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing
4. 304/316 stainless steel washing pump make the machine more durable .
Filling Part
1. During filling juice ,we will make a cover installed on the filling valve, avoiding the fruit pulp return inside reflux pipe to block the pipe.
2. Filling valve and bottle lifter uses adopts German Igus bearings which are corrosion-resistant and maintenance-free.
3. By install CIP cleaning cups, the filling machine can realize online CIP cleaning 4.During filling process, there is no reflux of product, avoiding blockage of product.
Capping Part
1. Place and capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping.
2. All 304/316 stainless steel construction
3. No bottle no capping
4. Automatic stop when lack of bottle
5. Capping effect is stable and reliable, Defective rate ≤0.2%
FAQ
Of course.Best quality is our principle all the time.You can be assured on our production.
2. What should I do if we are not able to operatethe the machine when we receive it?
Operation manual guides you the installation.Besides, we haveprofessional after-sale groupto customer 's site to solve any problems.weprovide 7*24 hours on-line technical support.
3. How could I get the spares on machines?
We will send extra sets of easy broken spares andaccessories likeo ring etc.Non-artificial damagedspares will be sent freelyduring 1 year 's warranty.
4. Can this machine fill paste or cream ?
The spout pouch filling machine can fill any liquidas juice,beverage,soy milk,cocktail and variouscondiments like tomato sauce,bean sauce etc.
5. How to maintain such a machine ?
Please clean every part after filling thus can givelong using life of machine and make a carefullyclean 3 times a year.
