Screw All In One Air Compressor 350 Lilter Air Tank Dryer Integrated Air Compressor
20hp 15kw Screw Air Compressor Integrated 350 Lilter Air Tank Dryer All In One Air Compressor
Product Advantages
The Air Compressor for Fiber Laser Cutting Machine
Integrated compressed air system includes screw compressor, refrigerated air dryer, tank specialized for fiber laser cutting machine.
More Convenient
Integration of air compressor, air tank, and air dryer. It avoids the trouble of customers purchasing additional pipes and fittings. Use directly after installation, saving space.
More Reliable
Modular design, durable components, low noise and vibration, and easy maintenance.
Energy Efficiency
Using permanent magnet variable speed motor, specialized for laser cutting machine, reducing pressure leakage and more energy-saving.
Pure Compressed Air
High efficiency refrigerated dryer, multi-stage precision filter, oil content of gas is lower than 0.001 PPM, ensuring the purity of compressed air.
Technical Parameters
| Model |
CPBZY15 |
|
Type |
Fixed air-cooled twin-screw air compressor |
|
Dimensions |
1900*700*1650mm |
|
Installation method |
Fixed installation without foundation |
|
Rated displacement |
1.16m3/min |
|
Rated exhaust pressure |
1.58Mpa |
|
Exhaust oil content |
≤0.003 ppm |
|
Exhaust pressure dew point |
2~10°C |
|
Compression stages |
Single-stage |
|
Transfer method |
belt |
|
Compression oil consumption |
8L |
| Cooling method | Air cooling |
| Cooling air volume | 3500 m3/h |
|
Ambient temperature |
0 ~ 45°C |
|
Noise |
≤65 dB |
|
Weight |
560kg |
Notes:
1. A represents air-cooling type,W represents water-cooling type;
2. Working Environment temperature: -5ºC~45ºC;
3. Discharge temperature is less than ambient temperature +10ºC~15ºC;
4. Drive Mode: belt driven;
5. Startup Mode: direct start under 11kw, and above 11kw;
6. Work Power: 380V / 50HZ, 460V / 230V / 6KV and 10KV voltages can be made for customers;
7. F.A.D volume flow test is according to ASMC PTC9 or ISO1217 standard (GB/T3853)
Dehaha 4-in-one (Compressor + receiver tank+ dryer + filters) high pressure air compressor is special compressor for Fiber Laser Cutting industry, custom built to provide filtered, dried, continuous reliable supply of high pressure compressed air at 2~10ºCdew point to assist laser cutting. Produce your own assist air at a fraction of the cost of cylinder.
Dehaha Compressor was founded in 1996 with over 150 skilled employees and more than 25 R&D engineersteams ’ . We focus on the research & develop,manufacture and energy-saving solutions of screw air compressor to create value for customers and society.In 2018 our total sales volume approached 15 million US dollars.By over 23 years enhanced experiences of designing,producing and marketing,today our valued customers are over 130 countries.
Germany Standard and 13 years exporting experience help us won more than 50 loyal overseas agents.
Dehaha’s primary businesses focus in following key areas:
Oil-injected rotary screw compressors
Portable screw air compressors
Oil free air compressors
High pressure air compressors
Air treatment equipment
