Integrated 15hp 11kW 4 In 1 Air Compressor For Laser Cutting Machine 350 Litre Air Tank
Price:
Negotiate
MOQ:
1set
Delivery Time:
20 days
Brand:
Dehaha
Product Description
4 in 1 Integrated Laser Cutter Screw Air Compressor Price with 350 Litre Air Tank
Model:CPMZY15A
![]()
Air delivery: 1.16m³/min
Working pressure: 16bar
Dimension:1900×700×1650mm
Compression oil amount:10L
Cooling air volume:350m3/h
Noise:≤65db
Speed:2930r/min
Air tank: 350L
Air dryer: 16bar/2.4m3/2-10℃
Filter: 16bar/2.8m3/4 pcs
Start mode: frequency conversion start
Start mode: frequency conversion start
Laser cutting machine power: Below 6000W Filter fineness, use four stage filters, particle
content≤0.01μm oil content≤0.003PPM
content≤0.01μm oil content≤0.003PPM
Equipment configuration: screw air compressor, air tank, air dryer, four stage filters, auto drain valve, inverter.
Pressure differentiation of integrated screw air compressor
1. High pressure series
(1) The appearance is integrated, with air tank and air dryer
(2) The pressure range is 16bar (232psi) -30bar (435psi)
(3) Divided into fixed speed and permanent magnet frequency conversion series
2. Ordinary pressure series
(1) The appearance is integrated, with air tank and air dryer
(2) The pressure range is 7bar (101.5psi) -13bar (188.5psi)
(3) Divided into fixed speed and permanent magnet frequency conversion series
Technical Parameters
| Model | Capacity (m3/min) |
Pressure
(Bar )
|
Power
(kw)
|
Noise
(DB)
|
Outlet diameter | Dimension(mm) |
Weight
(kg)
|
Air tank
(L)
|
Exhaust oil content(ppm) |
| DBZY-10A | 0.55 | 1.58 | 7.5 | 65 | G3/4 | 1418*700*1500 | 395 | 260 | 0.01 |
| DBZY-15A | 1.05 | 1.58 | 11 | 65 | G3/4 | 1882*790*1731 | 560 | 500 | 0.01 |
| DBZY-20A | 1.51 | 1.58 | 15 | 65 | G3/4 | 1882*790*1731 | 572 | 500 | 0.01 |
| DMZY-15A | 1.05 | 1.58 | 11 | 65 | G3/4 | 1882*790*1731 | 560 | 500 | 0.01 |
| DMZY-20A | 1.52 | 1.58 | 15 | 65 | G3/4 | 1882*790*1731 | 572 | 500 | 0.01 |
| DMZY-30A | 2.41 | 1.58 | 22 | 68 | G3/4 | 1882*1081*1801 | 630 | 500 | 0.01 |
| DCZY-30A | 2.21 | 1.58 | 22 | 68 | G3/4 | 1882*1081*1801 | 630 | 500 | 0.01 |
| CPBZY15A | 1.14 | 1.58 | 15 | 65 | G3/4 | 1900*700*1650 | 520 | 350 | 0.01 |
| CPMZY15A | 1.14 | 1.58 | 15 | 65 | G3/4 | 1900*700*1650 | 520 | 350 | 0.01 |
