China 22kw 30hp 30 bar Silent Screw Air Compressor Compresor de aire for Laser Cutting
Price:
Negotiate
MOQ:
1set
Delivery Time:
20 days
Brand:
Dehaha
Product Description
China 22kw 30hp 30 bar Silent Screw Air Compressor Compresor de aire for Laser Cutting
Model: DHH2030
Free air delivery: 2 m3/min
Working pressure: 30bar
Screw air end rotor lobe: 5:6
Control: PLC
Driven: belt
Cooling: by air
Electric motor: 30hp 22KW 380v/50hz/3ph IP54 grade
Discharge temperature: less than ambient +8 ℃
Noise: less than 65 dB(A)
Air outlet size: G3/4”
Dimension:2200*1600*1970mm
Weight: 1460kg
Technical Parameters
| Model | Capacity (m3/min) | Pressure(Bar ) | Power(kw) | Outlet diameter | Dimension(mm) | Weight(kg) |
| DHH1030 | 1 | 30 | 11 | G3/4" | 1650*1500*1970 | 1230 |
| DHH1230 | 1.2 | 30 | 15 | G3/4" |
1650*1500*1970
|
1300 |
| DHH1630 | 1.6 | 30 | 18.5 | G3/4" | 2200*1600*1970 | 1400 |
| DHH2030 | 2 | 30 | 22 | G3/4" | 2200*1600*1970 | 1460 |
Application Industry
Project Case
Client Feedback
Packing & Delivery
Company Profile
FAQ
