16 Bar 20hp Compresor de aire Fiber Laser Cutting Air Compressor with Air Dryer
Filter: 16bar/2.8m3/4 pcs
Start mode: frequency conversion start
Laser cutting machine power: Below 6000W
Filter fineness, use four stage filters, particle content≤0.01μm oil content≤0.003PPM
Equipment configuration: screw air compressor, air tank, air dryer, four stage filters, auto drain valve, inverter.
1. Reliable quality, competitive price
2. German Air end, 10 years manufacture experience
3. Perfect service network
4. Easy to install, operate, maintain.
5. Low noise, Low energy consumption, Low running, Low maintenance cost.
6. Aptitude and intelligent Control, PLC control, LCD displayer.
| Model |
Capacity (m3/min
/cfm)
|
Pressure (Mpa
/bar )
|
Power (kw/HP)
|
Noise
(DB)
|
Outlet diameter
|
Dimension(mm)
|
Weight
(kg)
|
Air tank(L)
|
|
DBZY-10A
|
0.55/19.4
|
1.58/15.8 |
7.5/10
|
65
|
G3/4
|
1418*700*1500
|
395
|
260
|
|
DBZY-15A
|
1.05/37.1
|
1.58/15.8
|
11/15
|
65
|
G3/4
|
1882*790*1731
|
560
|
500
|
|
DBZY-20A
|
1.51/53.3
|
1.58/15.8 |
15/20
|
65
|
G3/4
|
1882*790*1731
|
572
|
500
|
|
DMZY-15A
|
1.05/37.1
|
1.58/15.8
|
11/15
|
65
|
G3/4
|
1882*790*1731
|
560
|
500
|
|
DMZY-20A
|
1.52/53.7
|
1.58/15.8
|
15/20
|
65
|
G3/4
|
1882*790*1731
|
572
|
500
|
|
DMZY-30A
|
2.41/85.1
|
1.58/15.8
|
22/30
|
68
|
G3/4
|
1882*1081*1801
|
630
|
500
|
|
DCZY-30A
|
2.21/78
|
1.58/15.8
|
22/30
|
68
|
G3/4
|
1882*1081*1801
|
630
|
500
|
Q1. Are you trading company or manufacture ?
A: We are professional manufacture of screw air compressor of Jiangsu, China, more than 24 years.
Q2. How long is the delivery time ?
A: For standard voltage ,15 working days. Non-standard ,please contact our sales.
Q3. What's payment term ?
A: T/T, L/C, D/P, Western Union, Paypal, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.
Q4. How about your after-sales service ?
A: 1.Provide customers with installation and commissioning online instructions.
2. Well-trained engineers available to overseas service.
3.Worldwide agents and after service avaiable.arrange our engineers to help you training and installation.
Q5. How about your warranty?
A: One year for the whole machine and two years for screw air end, except consumable spare parts.
Q6. Do you have any certificate ?
A: Yes, per different customer's market need ,we can offer CE ,ISO etc certificate.
Q7. What about the maintenance ?
A: First maintenance need to be done after 500Hours, and then every 2000-3000 hours to do the normal maintenance, and consider the actual environment.
Q8. How do you control quality ?
A: 1.The raw materials are strictly inspected
2. Some key parts are imported from overseas
3.Each compressor must pass at least 5 hours of continuous testing before leaving the factory.
Q9. Do you offer OEM service ?
A: Yes.Both OEM & ODM service can be accepted.
