Stainless Steel 304 Woven Wire Mesh Screen 0.5m-30m Length
Price:
$1-$10
MOQ:
5Pcs
Delivery Time:
25 work days
Brand:
KDL
Product Description
Stainless Steel 304 Woven Wire Mesh Screen
High-quality corrosion-resistant woven wire mesh screen available in lengths from 0.5m to 30m, ideal for screening, filtration, and sieving applications across various industries.
Product Specifications
| Attribute | Value |
|---|---|
| Product Name | Stainless Steel Woven Wire Mesh |
| Weaving Type | Flat-Topped Curved |
| Packing | Pallet |
| Length | 0.5m To 30m |
| Application | Screening, Filtration, Sieving, Etc. |
| Opening Size | 0.5-400mm |
| Width | 0.5m-2.2m |
| Tensile Strength | 1000-1800MPa |
| Wire Diameter | 0.2mm To 15mm |
Product Description
Our woven wire mesh screen is constructed from high-quality stainless steel 304, offering excellent rust-proof and anti-corrosive properties. Designed for durability in demanding industrial environments including mining, construction, and coal processing facilities.
Available Configurations
| Wire Diameter (mm) | Aperture (mm) | Weight (kg/M²) | Standard Sizes |
|---|---|---|---|
| 0.75 | 1.00 | 4.29 | 1M×2M 1.5M×2M 2M×2.5M 1.22M×2.387M Customizable |
| 1.00 | 1.50 | 5.33 | |
| 1.50 | 2.00 | 8.57 | |
| 2.00 | 3.00 | 10.67 | |
| 3.00 | 4.00 | 17.15 | |
| 3.00 | 5.00 | 15.00 | |
| 3.50 | 6.00 | 17.20 | |
| 4.00 | 8.00 | 17.44 | |
| 4.00 | 10.00 | 14.95 | |
| 4.50 | 12.00 | 16.05 | |
| 4.50 | 12.50 | 15.58 | |
| 4.50 | 14.00 | 14.32 | |
| 5.00 | 16.00 | 15.57 | |
| 5.50 | 18.00 | 16.84 | |
| 5.50 | 19.00 | 16.15 | |
| 5.50 | 20.00 | 15.52 | |
| 6.50 | 22.00 | 19.39 | |
| 6.50 | 24.00 | 18.12 | |
| 6.50 | 25.00 | 17.55 | |
| 6.50 | 28.00 | 16.02 | |
| 7.00 | 32.00 | 16.44 | |
| 7.50 | 35.00 | 17.31 | |
| 7.50 | 38.00 | 16.17 | |
| 7.50 | 40.00 | 15.49 | |
| 7.50 | 45.00 | 14.02 | |
| 8.00 | 50.00 | 14.43 | |
| 9.00 | 63.00 | 14.72 | |
| 9.00 | 75.00 | 12.61 | |
| 11.00 | 100.00 | 14.26 |
Key Features
- Material: High-quality stainless steel 304 wire
- Surface treatment: Anti-rust oil or paint for enhanced durability
- Edge options: Flat edge or hooked edge available
- Corrosion, heat, and acid resistant
- Minimum order quantity: 1 piece
- Standard lead time: 7-15 days
- Ideal for vibrating screen applications
Applications
Manufactured in Anping, Hebei, our KDL brand woven wire mesh screen is engineered for demanding industrial applications including:
- Mining screen mesh
- Vibrating screen mesh
- Security screen mesh
- Stone crushing operations
- Industrial filtration systems
Customization Options
We offer complete customization services to meet specific project requirements:
- Custom sizes from 0.5m to 2.2m width and up to 30m length
- Special wire diameters from 0.2mm to 15mm
- Custom aperture sizes from 0.5mm to 400mm
- Choice of edge treatments (flat or hooked)
- Special surface treatments available
Packaging & Shipping
Our woven wire mesh screens are carefully packaged to ensure safe delivery:
- Packaged in rolls or sheets as required
- Protected with plastic wrap, foam, or cardboard
- Shipped via land, sea, or air depending on order size
- All shipments include proper labeling and tracking
Frequently Asked Questions
Q: What is the brand name of the Woven Wire Mesh Screen?
A: The brand name is KDL.
Q: Where is the Woven Wire Mesh Screen produced?
A: Our products are manufactured in Anping, Hebei.
Q: What are the primary uses of the Woven Wire Mesh Screen?
A: It's primarily used for screening, filtration, and sieving applications across various industries.
Q: What materials are used in production?
A: We use high-quality stainless steel wire for superior durability and performance.
Q: What is the maximum temperature rating?
A: Our mesh screens can withstand temperatures up to 600°C.
