China Galvanized Carbon Steel Seamless Pipe API 5L / A53 / A106 GR B Pipe for sale

Galvanized Carbon Steel Seamless Pipe API 5L / A53 / A106 GR B Pipe

Name: Galvanized Carbon Steel Seamless Pipe API 5L / A53 / A106 GR B Pipe
Brand: WUXI FENGERMAN IRON AND STEEL LIMITED

Price Negotiable

Price: $750.00 - $1000.00/ metric ton

MOQ: 1 ton

Delivery Time: 5-8 work days

Brand: BAOSTEEL,TISCO,RIZHAOSTEEL

Product Description

Manufacture China Carbon Steel Pipes A106b/ API5l/ API5CT Galvanized Seamless Carbon Steel Pipe

Product name	Seamless carbon steel pipe / Line Pipe
Material	API 5L /A53 /A106 GRADE B and other material which client inquired
Steel Grade	API 5L, GR B, X42, X46, X56, X60,X65,X70 ASTM A53.A106: GR A, GR B, GR C ASME SA106: GR. A, GR.B, GR.C ASME SA192: SA192 ASME SA209M: T1, T1a ASME SA210: GR.A-Q, GR.C ASME SA213: T2, T5,T9, T11, T12, T22 ASME SA335: P2, P5, P9, P11, P12, P22, P91 DIN7175: ST35.8,ST45.8,15Mo3, 13CrMo44
Outer Diameter	10.3- 1016mm
Wall Thickness	SCH10 SCH20 SCH30 STD SCH40 SCH60 XS SCH80 SCH100 SCH120 SCH140 SCH160 XXS
Length	Single random length/Double random length 5m-14m,5.8m,6m,10m-12m,12m or as customer's actual request
Ends	Plain end/Beveled,protected by plastic caps on both ends, cut quare,grooved,threaded and coupling,etc.
Heat Treatment	Annealed: Bright annealed, Spheroidize annealed, Normalized, Stress relieved, Cold finished, Quenched and Tempered
Surface Treatment	Bare,Painting black,varnished,galvanized,anti-corrosion 3PE PP/EP/FBE coating
Technical Methods	Hot-rolled/Cold-drawn/Hot-expanded
Testing Methods	Pressure test,Flaw detection,Eddy current testing, Hydro static testing or Ultrasonic examination and also with chemical and physical property inspection
Packaging	Small pipes in bundles with strong steel strips,large pieces in loose; Covered with plastic woven bags; Wooden cases;Suitable for lifting operation;Loaded in 20ft 40ft or 45ft container or in bulk; Also according to customer's requests
Application	Fluid pipe, oil pipe, gas pipe, structure pipe, boiler tubes
Test	Chemical Component Analysis, Mechanical Properties, Technical Properties, Exterior Size Inspection, Hydro static Test, X-ray Test.
Container size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM
The sizes or thicknesses of seamless pipe can be customized, if you need additional information, please don’t hesitate to contact us at any time.

DN	OD Outside Diameter		ASTM A53 GRA / B		BS1387 EN10255
DN	OD Outside Diameter		SCH10S	STD SCH40	LIGHT	MEDIUM	HEAVY
MM	INCH	MM	(mm)	(mm)	(mm)	(mm)	(mm)
15	1/2”	21.3	2.11	2.77	2	2.6	-
20	3/4”	26.7	2.11	2.87	2.3	2.6	3.2
25	1”	33.4	2.77	3.38	2.6	3.2	4
32	1-1/4”	42.2	2.77	3.56	2.6	3.2	4
40	1-1/2”	48.3	2.77	3.68	2.9	3.2	4
50	2”	60.3	2.77	3.91	2.9	3.6	4.5
65	2-1/2”	73	3.05	5.16	3.2	3.6	4.5
80	3”	88.9	3.05	5.49	3.2	4	5
100	4”	114.3	3.05	6.02	3.6	4.5	5.4
125	5”	141.3	3.4	6.55	-	5	5.4
150	6”	168.3	3.4	7.11	-	5	5.4
200	8”	219.1	3.76	8.18	-	-	-
