4Port Fiber Optic Terminal Box SC UPC SX SM White IP66 For Telecommunication
Price:
Negotiate
MOQ:
Negotiate
Delivery Time:
3-8 work days
Brand:
Twilight Optic
Product Description
4Port Fiber Optic Terminal Box SC UPC SX SM White IP66 For Telecommunication
Description
FAT-4B fiber access termination box is able to hold up to 4 subscribers. It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system. It integrates fiber splicing, splitting, distribution, storage and cable connection in one solid protection box.
| Name | 4Cores Fiber Optic Distribution Enclosure With Plug |
| Application | FTTx solutions |
| Material | PC+ABS |
| Color | White |
| Size | 191*120*44mm |
| Weight | 0.8KG |
| Protection Level | IP66 |
| Insertion Loss | ＜0.2dB |
| Adapter | SC/LC/ST/FC |
| Cable Type | SM/MM/OM1/OM2/OM3/OM4 |
Features
► Water-proof design with IP-66 Protection level.
► Integrated with splice cassette and cable management rods.
► Manage fibers in a reasonable fiber radius condition.
► Easy to maintain and extend the capacity.
► Fiber bend radius control more than 40mm.
► Suitable for the fusion splice or mechanical splice.
► Efficient cable management.
► 4 ports cable entrance for drop cable.
Configuration
| Material | Size | Max Capacity | Installation Size | Weight | Color | ||
| PC+ABS |
A*B*C(MM) 191*120*44 |
SC 4 Ports |
LC 8 Ports |
PLC 1X4(SC) |
D(MM) 185 |
0.8KG | White |
Details Picture
