128X64 Graphic LCD Module STN Gray Display With White Side Backlight
128X64 Graphic LCD Module STN Gray Display With White Side Backlight
128X64 Graphic LCD Module | STN + Gray Display With White Side Backlight/HTM12864-30
HTG12864-30 | Monochrome Graphic Module | 128x64 Pixels | Transflective LCD | Side White Backlight | STN (+) Positive Gray Display | IN-STOCK
HOTLCD 128x64 graphic Liquid Crystal Display module shows blue pixels on a gray background. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -20 to 70 degrees Celsius. This HTG12864-30 display has a built-in temperature compensation circuit and negative voltage. It has an optimal view of 6:00, operates at 5V supply voltage and is RoHS compliant.
Mechanical Data
|
Item |
Standard Value |
Unit |
|---|---|---|
|
Module Dimension |
144.0x98.0x 9.1 |
mm |
|
Viewing Area |
114.0 x 64.0 |
mm |
|
Mounting Hole |
107.44 x 57.51 |
mm |
|
Dot Pitch |
0.90x0.84 |
mm |
|
Dot Size |
0.82x0.76 |
mm |
Electrical Characteristics
|
Item |
Symbol |
Standard Value |
Unit |
|---|---|---|---|
|
Input Voltage |
VDD |
5.0 |
V |
Search Keyword: 128x64 lcd, 128 x 64 lcd, lcd 128 x 64
LCD Custom Solutions
Cable Customization
Adjust the length, position, and pinout of your cables or add additional connectors. Get a cable solution that’s precisely designed to make your connections streamlined and secure.
Connector Customization
Easily modify any connectors on your display to meet your application’s requirements. Our engineers are able to perform soldering for pin headers, boxed headers, right angle headers, and any other connectors your display may require.
Interface Customization
Choose from a wide selection of interface options or talk to our experts to select the best one for your project. We can incorporate HI, USB, SPI, VGA and more into your display to achieve your design goals.
PCB Modifications
Choose from a wide selection of changes including shape, size, pinout, and component layout of your PCB to make it a perfect fit for your application.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
