China Auxiliary Engineering Reinforced 3D Geomat Geonet material for sale

Auxiliary Engineering Reinforced 3D Geomat Geonet material

Price Negotiable

Price: 0.55 USD~3.5USD per sqm

MOQ: 1000sqm

Delivery Time: 5~8 working days according to actual quantity

Brand: wanshengli

Product Description

As a helper for maintenance and auxiliary engineering construction, the geonet is also very convenient in use.

3D Geomat is a new type of geosynthetic material with three-dimensional structure suitable for soil and water conservation, which can effectively prevent soil and water loss, increase green area, and improve the ecological environment. Due to the use of polymer materials and UV anti-ultraviolet stabilizers, geomat has higher chemical stability and no pollution to the environment.

Product Parameter

Item	EM2	EM3	EM4	EM5
Layer	2	3	4	5
Unit Weight≥(g/m2)	220	260	350	430
Thickness≥(mm)	10	12	14	16
Breaking Load(LD)≥(KN/M)	0.8	1.4	2	3.2
Elongation (%)	<30
Color	Black, Green
Carbon Black (%)	2
Raw Material	HDPE, UV
Dimension/Roll (WXL)	2X50m	2X50m	2X50m	2X50m
20GP(m2)	4500	4000	3500	3000
40GP(m2)	10000	9000	8000	7500

Applications

1. Highway and railway subgrade strengthen: effectively distribute load, improve its bearing capacity and stability and prolong service life

3. Highway slope protection: prevent landslide and protect water and soil, and beautify the environment

4. In reservoir and rive dykes to effectively prevent landslide

4.Widely used in the coastal engineering due to its soft good toughness, corrosion strong characteristic to buffer wave swept and corrosion

index		BFD30-30	BFD40-40	BFD50-50	BFD80-80	BFD100-100	BFD125-125	BFD150-150
Grid size		12.712.7 25.425.4 50.8*50.8
Bonding strength kN/m	verticcal	≥30	≥40	≥50	≥80	≥100	≥125	≥150
Bonding strength kN/m	crosswise	≥30	≥40	≥50	≥80	≥100	≥125	≥150
extensibility(%)		≤4
temperature toleration		-100~~280

Features: The product has the characteristics of high strength, low elongation, high temperature resistance, high modulus, light weight, good toughness, corrosion resistance and long service life. It can be widely used in engineering fields such as maintenance of old cement pavement, airport runway, dam, river bank, slope protection, road and bridge pavement reinforcement treatment, etc., and can strengthen and reinforce the pavement, prevent pavement rutting fatigue crack, hot and cold expansion crack and reflection crack below, and disperse the pavement bearing stress, prolong the service life of the pavement, with high tensile strength, low elongation, no long-term creep, good physical and chemical stability, good thermal stability, fatigue cracking resistance and high temperature rutting resistance.

指标	BSD30-30	BSD40-40	BSD50-50	BSD60-60	BSD80-80	BSD100-100	BSD150-150
纵向抗拉强度kN/m	≥30	≥40	≥50	≥60	≥80	≥100	≥150
横向抗拉强度kN/m	≥30	≥40	≥50	≥60	≥80	≥100	≥150
总横向延伸率(%)	≤2
伸长率1%时纵向抗拉强度kN/m	≥20	≥32	≥40	≥48	≥63	≥81	≥125
伸长率1%时横向抗拉强度kN/m	≥20	≥32	≥40	≥48	≥63	≥81	≥125
粘焊点极限剥离力	≥100	≥100	≥100	≥100	≥100	≥100	≥100
