Textile Test Equipment Automatic Shrinkage Testing Machine FZ/T70009,ISO5077/6330,IWS TM31 HZ-8014
Equipment discription:
Ten sets of the equipment set the standard for an automatic washing process, Huan the user will choose different test conditions and test Guo Cheng, an increase of users own an automatic Scrubbing Process Flow set, and can be manually controlled single process, Qi wide application, easy to use. Apply to plant or central laboratory on cotton, wool, linen, knitting, fiber, fabrics, garments or other textile products after washing shrinkage and relaxation tests.
Main feature:
1, instrument performance in line with GB, FZ, ISO, IWS, BS, EN, JIS, M & S and other standards.
2, support the personalized programming, to provide self-programming memory.
3 built-in load cell, capacity, easy to control accurately.
4, floating gallbladder wall structure, operation and automatically adjust the dynamic balance test.
5 import percussive motor drive, up to the high dehydration factor.
6, pressure sensor water level detection, accurate stable.
7, single-phase 220V power supply, can be the same as ordinary washing machine to use at any occasion.
Coresponding standard:
GB/T8629—2001,FZ/T70009,ISO5077/6330,IWS TM31,BS 4923,EN25077/26330 JIS L1909,Marks and Spencers and other testing standards.
Technical parameter:
| Model | HZ-8014 |
| typed | A washing machine - front feeding, horizontal cylinder |
| Weighing range | 0-50kg |
| Automatic weighting | Accuracy:0.05 kg; Resolution:0.01 kg |
| Inner cylinder diameter | (51.5±0.5)cm |
| The depth of the inner drum | (33.5±0.5)cm |
| Inside and outside the cylinder space | (2.8±0.1)cm |
| Enhance the volume | 3(distance120°) |
| Enhance the height | (5±0.5)cm |
|
Rotary action |
1. Nomal:Clockwise (12±0.1)s,stop(3±0.1)s Counterclockwise (12±0.1)s,stop(3±0.1)s |
|
1. Mild:Clcokwise (3±0.1)s,stop(12±0.1)s Counterclockwise(3±0.1)s,stop(12±0.1)s |
|
| Speed | Digital set, stepless,Up 40-1100r/min, washing 52r/min, dehydration (500 ± 20) r / min |
| Water injection | to 13 cm high and less than 2min |
| Drainage time | to 13 cm high and less than 1 min |
| Water level control | Low: 10cm Hight:13cm |
| Water level detection | Pressure sensors, digital setting range 0-150mm ± 1mm |
| Temperature detection | Temperature sensors, digital set range: room temperature -99 degree centigrade ± 1 degree centigrade Resolution: 0.1 degree centigrade |
| Washing procedure | 10 sets of automatic washing process file up to 5 sets of self-cleaning process manually editing individual control flow |
| Heating power | 5.4±2%KW |
| Rated loadin capacity | 5 kg |
| Operation display | 1. 240×128 LCD 2. 750×180mm Large area thin film panels |
| Outside dimension | (750×700×1200)mm(L×W×H) |
| Weight | 200Kg |
| Power | Ac220V 50Hz 6.5KW |
