EV Charging Cable European Standard 11kw 22kw 16A 32A Type2 To Type2 Charging Cable
Product Description:
Flame Resistance Ensured:
Carrying a UL94 V-0 classification, our product guarantees flame retardancy, emphasizing safety and security.
Enhanced Rear-End Defense:
A reinforced rear-end protection system has been integrated to bolster resilience and safeguard the charger.
Designed for Comfort:
The ergonomic design elevates user experience, promoting ease of use while enhancing the aesthetic appeal.
Aesthetic Appeal:
Meticulously coordinated design colors not only please the eye but also infuse a sense of enjoyment and style into the charging process.
Built to Last with Premium Materials:
A silicone protective layer envelopes the plug, augmenting grip and durability, ensuring it stays securely in place.
Exemplary Protection Measures:
With an IP65 rating in operational state, our product guarantees outstanding protection against outdoor elements like rain, snow, and high temperatures, ensuring reliable functionality.
Technical Parameters:
| Rated current | 16A/32A |
| Operation Volatge | 250V/480V |
| Insulation resistance | more than 500M Ohm(DC500V) |
| Contact resistance | 0.5m Ohm max |
| Terminal temperature rise | less than 50K |
| Withstand voltage | 2000V |
| Mechanical Properties: | |
| Mechanical life | no-load plug in/out more than 10000 times |
| Coupled insertion force | 45N~100N |
| Impact of external force | can afford 1M drop |
| Environmental Performance | |
| Operating Temperature | -30~+50ºC |
| Applied Materials | |
| Case material | thermoplastic, flame retardant grade UL94 V-0 |
| Termminal | Copper alloy , silver plating |
CAUTION:
1. Don't submerge the EV charging cable in water.
2. Don't step on, fold, or knot the cable.
3. Don't drop the EV charging box place a heavy object on it.
4. Don't place the charging cable near a high-temperature object when charging.
5. Don't operate the EVSE in temperatures beyond its operating range of-25°C to 55°C.
Packing and Shipping:
Packaging and Shipping Portable Electric Car Chargers
Our Portable Electric Car Chargers will be carefully enclosed in a custom-designed box to guarantee their safety during transportation. Crafted from durable corrugated cardboard, the box will be sealed using reinforced tape, providing an added layer of security to withstand the rigors of shipping.
FAQ:
1.Can we require you to do our trademark?
Trademark service is available,and the order quantity should be more than 100pcs.
2.What are your terms of delivery?
EXW, FOB, CFR, CIF, DDU, etc.
3.Can you produce according to the samples?
Yes,we could produce based on your samples or technical drawings.
4.What is your sample policy?
We can provide a sampleupon request.
Customers need to pay for the shipping cost.
