500W 550 Watts 600w Thin Film Flat Monocrystalline PV Panels Module Roof Mounting
Price:
Negotiable
MOQ:
1000Watts
Delivery Time:
With 1~3 Weeks
Brand:
ASGOFT
Product Description
China Cheap Vendors Solares Paneles 500 Watt 550 Watts 600w Thin Film Flat Mono Roof Mounting Solar Panel
Description:
Excellent Performance - ASGOFT solar panels use high-performance monocrystalline solar cells, which can provide up to 21.5% higher efficiency sufficient light conditions.
Outstanding Quality - 600W latest upgraded solar module improves conversion efficiency, reduces cells loss, and extends panel life. Excellent performance is also ensured in a low-light environment.
Features:
- Low-iron tempered glass
- Rugged aluminum frame
- The perfect all weather panel
- High-efficiency & high output
- Easy setup and fit all roof types
Specifications:
| Electrical Parameters at STC | |
| Module Type | ASS600P |
| Rate Maximum Power | 600 |
| Module Efficiency(%) | 21.5 |
| Open Circuite Volatage(Voc/v) | 54.1 |
| Short Circuit Current (Isc/A) | 14.1 |
| Voltage at Pmax (Vmp/V) | 45.53 |
| Current at Pmax (Imp/A) | 13.18 |
| Power Tolerance | 0~+5w |
| Temperature Coefficent of Isc | +0.046% °C |
| Temperature Coefficent of Voc | -0.276% °C |
| Temperature Coefficent of Pmax | -0.356% °C |
| STC | Irradiance 1000W/㎡ Cell Temperature 25°C AM 1.5 |
| Remark : Electrical data in this catalogue does not refer to a single module ,and it is not part of the offer . | |
| Solar Cell(Type/Size) | MONO(182mm) |
| Solar Cells Number | 156pcs (6*26) |
| Dimensions | 2464*1134*35mm |
| Weight | 30.0kg/pcs |
| Structure | 3.2Glass+EVA film+Back |
| Fram | Anodized Aluminum Alloy |
| Junction Box | IP68☒3*Bypass Diode |
| Cable Cross Section Size | 4.0m㎡,(+)280mm/(-)400mm |
| Mechanical Load | Front 5400Pa/Black 2400Pa |
| Packing Number | 31pcs/pallet |
| Packing Volume | 3.542cbm/pallet |
| 40'HQ Container | 590pcs |
Product Details :
FAQ
1. Who are we? What we do?
We are based in Shenzhen, China, focus on ESS battery solution for clients all over the world.
There are high-profile R&D , top management and sales teams.
ODM/OEM is available.
2. How do we guarantee the product warranty?
There is 5 to 10 years' warranty period.
3.How long is the lead time of sample order and production order?
About 1-2 weeks for sample order.
About 2-4 weeks for production order.
4. How long is the shipment?
About 2 weeks via air,3-7 weeks via sea, depending on the destination.
5. How do we offer the after-sales service?
We're ready for 24/7 service.
