High Voltage Solar Battery 15kw-40kw Household Solar Energy System Solar Power Bank With Lithium Battery
High Voltage Solar Battery 15kw-40kw Household Solar Energy System Solar Power Bank With Lithium Battery
Description:
High-voltage energy storage battery systems excel in the following application scenarios:
Home Energy Storage: High-voltage energy storage battery systems can be used for home energy storage, enabling households to store electricity during off-peak hours and utilize the stored energy during peak periods or power outages. This helps reduce energy consumption costs and provides a reliable backup power source.
Commercial and Industrial Applications: High-voltage energy storage battery systems are widely employed in commercial and industrial settings. For instance, commercial buildings and offices can utilize energy storage systems to smooth out energy demand and lower energy costs. Industrial enterprises can use storage systems as backup power sources to maintain the operation of critical equipment during power outages or emergencies.
Integration with Renewable Energy: High-voltage energy storage battery systems integrate seamlessly with renewable energy sources such as solar and wind power. They can store excess electricity generated during high-output periods and provide a stable energy supply during low-output periods. This helps balance energy supply and demand and improves the utilization of renewable energy.
Grid Regulation: High-voltage energy storage battery systems can be used for grid regulation by storing and releasing electricity to balance grid loads. This is particularly useful for addressing frequent fluctuations in the grid, uneven power loads, or peak demand situations, thereby enhancing grid stability and reliability.
Electric Transportation: High-voltage energy storage battery systems play a vital role in the field of electric transportation. They provide high energy density and fast charging capabilities, extending the driving range of electric vehicles and improving charging efficiency.
In summary, high-voltage energy storage battery systems exhibit excellent performance in home energy storage, commercial and industrial applications, integration with renewable energy, grid regulation, and electric transportation. They offer reliable solutions for energy storage and utilization.
Features :
- Product Item: ASH-3072100
- Capacity: 100ah
- Voltage: 153.6V 204.8V 256V 307.2V 358.4V 409.6V
- Output power: 15kWh 20kWh 25kWh 30kWh 35kWh 40kWh
- Material: EVE lithium iron phosphate battery
- Description: High Voltage Stackable Home energy storage battery
Specifications:
| Nominal Voltage | 153.6V 204.8V 256V 307.2V 358.4V 409.6V |
| Nominal capacity | 100AH |
| Nominal energy | 15kWh 20kWh 25kWh 30kWh 35kWh 40kWh |
| Dimension(L*W*H, MM) |
610*386*650 mm 610*386*795 mm 610*386*940 mm 610*386*1085 mm 610*386*1230 mm 610*386*1375 mm |
| Battery Cell Specifications: | EVE lithium iron phosphate battery |
| Max charging Current | 50A |
| Max Discharging Current | 60A |
| Internal resistance | ≤40 mΩ |
| Operating temperature(charge) | -22°C ~ 55°C |
| Storage temperature | -20°C ~ 25°C |
| Cell overcharge Protection |
Overcharge detection voltage
overcharge detection delay time
Overcharge release voltage
|
| Cell over-discharge Protection | Yes |
| Over-current Protection | Yes |
| Short Protection | Yes |
| Temperature Protection | Yes |
| Communication | CAN and RS485 |
| Cycle lfe | 8000 times(25°C@50%DOD,0.2C) |
| 6000 times(25°C@80%DOD,0.2C) | |
| 4000 times(25°C@100%DOD,1C) | |
| Life Span |
15-25 years Life span. Warranty: 5-10 years (Optional) |
