Lithium Ion Battery Wall Mounted 48V LiFePO4 200ah 10kw 20kw 300kw 50kw Energy Storage Battery

Price Negotiable
Price: negotiated
MOQ: negotiated
Delivery Time: negotiated
Product Description

Lithium Ion Battery Wall Mounted 48V LiFePO4 200ah 10kw 20kw 300kw 50kw Energy Storage Battery






Product Paramenters


Basic parameters
Type of electric core
PMD square electric core - 3.2V100Ah
Rated capacity
100Ah
200Ah
Rated total energy
5.12Kwh
10.24Kwh
Rated voltage
51.2V
Voltage range
43.2~58.4V

AC side parameters
Rated output power
5000W
Rated output voltage
230Vac(200/208/220/240Vac can be set) ± 5%
Output frequency range
50Hz士0.3Hz/60Hz 0.3 Hz
Efficiency
input>95%, output>90%
PV power generation parameters
Maximum output power
5000W
MPPT voltage range
120-450V
Solar charging current
0-80A settable






system parameter
Weight
45kg
80kg
Dimensions(H*W*D)
850*480*160mm
1100*480*180mm
Protection grade
IP54
Cooling mode
forced air cooling

Operating environment
Charging
0℃~55℃
Discharge
-20℃-60℃
Storage
- 10℃-45℃
Operating humidity
5-95%, relative humidity
Installation type
wall mounted
Communication mode
CAN,RS485,RS232
Company Profile

Guangzhou Pei Mengdan New Energy Co., LTD. (referred to as PMD New Energy) is a high-tech enterprise specializing in the research and development, production and sales of lithium batteries. PMD New Energy has a strong R & D team and the most advanced automated production equipment and manufacturing process in China. The total production capacity of our factory reaches 300,000 AH/day. Products are widely used in consumer electronics, solar energy storage products, inclusive vehicles, medical devices and other fields. PMD New Energy insists on protecting the environment and creating high-quality products. The company fully implements lS0900:2008 quality management system and iso14001:2004 environmental system. Products have passed UN38.3, CE, UL, ROHS and other international certification. We are always working to improve existing products and create new models. We are willing to provide you with quality products at the most reasonable price and serve you wholeheartedly. You win, we win.



FAQ

1. who are we?

We are based in Guangdong, China, start from 2001,sell to Domestic Market(55.00%),Western Europe(21.00%),North America(14.00%),Eastern Asia(6.00%),South Asia(1.00%),Eastern Europe(1.00%),Mid East(1.00%),Southeast Asia(1.00%),South America(0.00%),Oceania(0.00%),Southern Europe(0.00%),Central America(0.00%),Northern Europe(0.00%),Africa(0.00%). There are total about 1000+ people in our office.



2. how can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment;



3. what services can we provide?

Accepted Delivery Terms: FOB,CIF,EXW;

Accepted Payment Currency:USD,EUR,HKD,CNY;

Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash,Escrow;

Language Spoken:English,Chinese,Russian



4. Moq: 1 piece
