UWT1C471MNL1GS Electronic Components Capacitors RadialCan SMD Integrated Circuits Controllers
UWT1C471MNL1GS RadialCan-SMD Integrated Circuits Controllers Magnets Sensor Matched
| TYPE | DESCRIPTION |
| Category | Capacitors |
| Aluminum Electrolytic Capacitors | |
| Mfr | Nichicon |
| Series | UWT |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Active |
| Capacitance | 470 µF |
| Tolerance | ±20% |
| Voltage - Rated | 16 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 230 mA @ 120 Hz |
| Ripple Current @ High Frequency | 345 mA @ 10 kHz |
| Lead Spacing | - |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.394" (10.00mm) |
| Surface Mount Land Size | 0.327" L x 0.327" W (8.30mm x 8.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
Documents & Media
| RESOURCE TYPE | LINK |
| Datasheets | UWT Series |
| Chip Type Tape Spec | |
| Aluminum Electrolytic Land, Reflow | |
| Video File | Doctor Capacitor® Episode Eight: Nichicon Kitchen (or, all about soldering) |
| Doctor Capacitor® Episode Seven: What's In The Mail, Doc? | |
| Doctor Capacitor® Episode Nine: You Callin' Me? | |
| Doctor Capacitor Episode Two: Terms | |
| Doctor Capacitor Episode Three: Failure Modes | |
| EDA Models | UWT1C471MNL1GS - Models |
Environmental & Export Classifications
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8532.22.0020 |
Additional Resources
| ATTRIBUTE | DESCRIPTION |
| Other Names | 493-2181-1 |
| 493-2181-2 | |
| 493-2181-6 | |
| Standard Package | 500 |
