UVZ1H103MRD Electronic Components Capacitors CAP ALUM 10000UF 20% 50V RADIAL
UVZ1H103MRD BOM Service CAP ALUM 10000UF 20% 50V RADIAL UVZ1H103MRD
| TYPE | DESCRIPTION |
| Category | Capacitors |
| Aluminum Electrolytic Capacitors | |
| Mfr | Nichicon |
| Series | UVZ |
| Package | Bulk |
| Product Status | Obsolete |
| Capacitance | 10000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.85 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.2775 A @ 10 kHz |
| Lead Spacing | 0.492" (12.50mm) |
| Size / Dimension | 0.984" Dia (25.00mm) |
| Height - Seated (Max) | 2.047" (52.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
Documents & Media
| RESOURCE TYPE | LINK |
| Datasheets | UVZ Series |
| Miniature Type Taping Spec | |
| Video File | Doctor Capacitor® Episode Eight: Nichicon Kitchen (or, all about soldering) |
| Doctor Capacitor® Episode Nine: You Callin' Me? | |
| Doctor Capacitor® Episode Seven: What's In The Mail, Doc? | |
| Doctor Capacitor Episode Two: Terms | |
| Doctor Capacitor Episode Three: Failure Modes | |
| Design Resources | 20 W Non-Isolated Buck LED Driver Using PL LNK460KG |
| HTML Datasheet | UVZ Series |
| Miniature Type Taping Spec | |
| EDA Models | UVZ1H103MRD - Models |
Environmental & Export Classifications
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8532.22.0040 |
Additional Resources
| ATTRIBUTE | DESCRIPTION |
| Other Names | 493-1350 |
| Standard Package | 140 |
