Low Voltage Battery 8KW Three Phase Hybrid Inverter Off Grid Hybrid 2 MPPT
MOQ:
1 Pieces
Delivery Time:
30 days
Brand:
Deye Hybrid Inverter
Product Description
In stock Deye 8KW Three Phase hybrid inverter 2 MPPT Low Voltage Battery Hybrid Inverter with battery storage
Product Description
SUN-5/6/8/10/12K-SG04LP3 | 5-12kW | Three Phase | 2 MPPT | Hybrid Inverter | Low Voltage Battery
Higher yields / Safe & Reliable / Smart / User-friendly
SUN 5/6/8/10/12K-SG is brand new three phase hybrid inverter with low battery voltage 48V, ensuring system safe and reliable. With compact design and high-power density, this series supports 1.3 DC/AC ratio, saving device investment. It supports three phase unbalanced output, extending the application scenarios. Equipped with CAN port (x2) BMS and parallel, x1 RS485 port for BMS, x1 RS232 port for remotely control, x1 DRM port, which makes the system smart and flexible.
Smart Monitoring Platform
Thanks to the smart monitoring platform, Deye full series inverter products support remotely shutdown immediately when accident occurs.Setting parameters and FW update remotely, which makes PV plant O&M easier.
- 48V low voltage battery, transformer isolation design
- 6 time periods for battery charging/discharging
- Max. charging/discharging current of 240A
- Max.10pcs parallel
- DC couple and AC couple to retrofit existing solar system
- Support storing energy from diesel generator
- Supports three phase unbalanced output
- Unique Smart Load application and Grid peak shaving function
Specification
|
item
|
value
|
|
Place of Origin
|
China
|
|
Guangdong
|
|
|
Brand Name
|
Deye Hybrid Inverter
|
|
Model Number
|
SUN-8K-SG04LP3-EU
|
|
Input Voltage
|
550V (160V~800V)
|
|
Output Voltage
|
200V-650V (Three phase)
|
|
Output Current
|
18.2 A
|
|
Output Frequency
|
50/60 HZ
|
|
Output Type
|
Triple
|
|
Size
|
422*699.3*279mm
|
|
Type
|
DC/AC Inverters
|
|
Inverter Efficiency
|
97.6%
|
|
Certificate
|
IEC
|
|
Warranty
|
5 Years
|
|
Weight
|
33.6 KGS
|
|
Color
|
White
|
|
Inverter type
|
DC/AC Inverters
|
|
Max DC Input Power(W)
|
10400
|
|
Rated PV Input Voltage (V)
|
550(160-800)
|
|
MPPT Voltage Range(V)
|
200-650
|
|
Full Load DC Voltage Range(V)
|
350-650
|
|
PV Input Current(A)
|
13+13
|
|
Max PV ISC (A)
|
17+17
|
|
Number of MPPT/Strings per MPPT
|
2/1+1
|
Packing & Delivery
Company Profile
Kweight Power Ltd is one of the earliest companies has 17 years experience in battery products R&D, production and sales. We run maintenance-free VRLA battery,Deep cycle battery,Gel battery,Solar battery, Li-ion battery and batteries for UPS, ESS, Off-grid power and other types of energy storage storage. We have launched many series of battery products developed and designed by our own brand. Our company covers more than 50000 square meters. Its comprehensive strength is getting closer with some world-class Level VRLA battery manufacturers after about 10 years' development. By means of several times of large-scale technology improvement with some domestic and overseas professional organizations and relative companies, our product quality, technology and service can be rated as world-class level. We use the most advanced professional equipment to manufacture batteries and do quality control. And our annual production capacity is approx. 280 million Vah. Since establishment of our company, We actively promote the comprehensive quality control system, treat the quality of the products as company's life. We have passed the ISO9001 Quality Management system, RoHS Environmental Management System, CE and American certificate etc.
FAQ
1. who are we?
We are based in Guangdong, China, start from 2007,sell to Oceania(13.00%),North America(12.00%),Western Europe(10.00%),Northern Europe(9.00%),Eastern Europe(8.00%),South America(8.00%),Mid East(8.00%),Africa(8.00%),Southern Europe(6.00%),Domestic Market(5.00%),Central America(5.00%),South Asia(3.00%),Southeast Asia(3.00%),Eastern Asia(2.00%). There are total about 1000+ people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Lithium Battery,LifePO4 Battery,Solar Lithium Battery,PORTABLE POWER STATION,LEAD-ACID BATTERY
4. why should you buy from us not from other suppliers?
As a leading company with 17 years experience in products R&D, production and sales, we run maintenance-free VRLA battery, Li-ion battery, and batteries for Off-Grid power, UPS, and ESS. We'll design and offer energy solutions for our clients in every case
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,Express Delivery;
Accepted Payment Currency:USD,EUR,AUD,GBP;
Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
We are based in Guangdong, China, start from 2007,sell to Oceania(13.00%),North America(12.00%),Western Europe(10.00%),Northern Europe(9.00%),Eastern Europe(8.00%),South America(8.00%),Mid East(8.00%),Africa(8.00%),Southern Europe(6.00%),Domestic Market(5.00%),Central America(5.00%),South Asia(3.00%),Southeast Asia(3.00%),Eastern Asia(2.00%). There are total about 1000+ people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Lithium Battery,LifePO4 Battery,Solar Lithium Battery,PORTABLE POWER STATION,LEAD-ACID BATTERY
4. why should you buy from us not from other suppliers?
As a leading company with 17 years experience in products R&D, production and sales, we run maintenance-free VRLA battery, Li-ion battery, and batteries for Off-Grid power, UPS, and ESS. We'll design and offer energy solutions for our clients in every case
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,Express Delivery;
Accepted Payment Currency:USD,EUR,AUD,GBP;
Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
