5V Stainless Steel Car MAP Sensor Automotive Vacuum Pressure Sensor
Product Description:
A Manifold Absolute Pressure (MAP) Sensor is a device that measures the amount of pressure within a car's intake manifold. It is usually located either beside, or directly onto, the throttle body. The intake manifold pressure that the MAP Sensor gives to the Engine Control Unit (ECU) is used by the ECU to calculate the air density and adjust the air to fuel ratio being used for the combustion process. This enhances the car's performance since the ECU can adjust the engine's load, fuel injection pulse to control the rate of fuel entering the engine, and modify the ignition timing.
Apart from such general uses, MAP sensors can also be used to diagnose a car's potential throttle performance issues, check for a vacuum leak in the intake manifold, figure out air mass measurements through recordings of engine speed and Intake Air Temperature, as well as provide a backup when testing the working condition of the Exhaust Gas Recirculation or EGR valve in vehicles with mass airflow – MAF – sensors, which tracks air density and volumetric air flow.
Common causes of a MAP Sensor Failure include being contaminated, clogged, having electronics damaged from the intense heat generated by the engine, or vibration damage from prolonged exposure to the engine compartment. Some symptoms of a faulty MAP Sensor include an engine that will not start (or starts poorly), detonation or misfire, excessive fuel consumptions, lack of engine power, as well as an illuminated Check Engine Light.
Features:
- Product Name: automotive MAP sensor
- Manufacturer: XYZ
- Accuracy: ±0.5%
- Connector Type: 3-pin
- Operating Temperature: -40 To 125°C
- Weight: 20 G
- Function: Engine Control Unit Pressure Sensor, Intake Air Pressure Sensor, Automotive Boost Pressure Sensor
Technical Parameters:
| Parameter | Description |
|---|---|
| Warranty | 2 Years |
| Housing Material | Stainless Steel |
| Power Supply | 5 V |
| Output Signal | 0.5-4.5 V |
| Protection Level | IP67 |
| Weight | 20 G |
| Dimensions | 30 X 18 X 10 Mm |
| Operating Temperature | -40 To 125°C |
| Connector Type | 3-pin |
| Accuracy | ±0.5% |
| Product Name | Manifold Air Pressure Sensor, Intake Manifold Absolute Pressure Sensor, Intake Manifold Pressure Sensor |
Applications:
Oetex Manifold Absolute Pressure Sensor (MAP Sensor) is designed specifically for automotive applications. It is certified by ISO9001 and has an operating temperature range of -40 to 125°C. It is highly reliable with a protection level of IP67, making it suitable for a wide variety of operating conditions. It is powered by 5V and outputs a signal between 0.5 - 4.5V. The pressure range is 0-5 Bar. It is perfect for engine control unit pressure sensor applications and manifold air pressure sensor applications.
This MAP sensor from Oetex is ideal for modern automotive engines as it provides the highest accuracy and reliability. It is designed to meet the highest standards and comes with a long-term warranty to ensure customer satisfaction. It is easy to install and maintain, making it a great choice for automotive applications.
Customization:
- Brand Name: Oetex
- Certification: ISO 9001
- Accuracy: ±0.5%
- Operating Temperature: -40 To 125°C
- Product Name: Automotive MAP Sensor
- Power Supply: 5 V
- Weight: 20 G
- Application: Engine Control Unit Pressure Sensor, Engine Management Pressure Sensor, Engine Management Pressure Sensor
Support and Services:
At Company Name, we are committed to providing the highest quality technical support and service for our automotive MAP sensor. Our team of certified professionals is committed to providing the best service and support to ensure the optimal performance of your automotive MAP sensor.
We have a range of services and support options available to you. These include:
- Technical Troubleshooting & Diagnostics
- Installation and Setup Assistance
- Software and Firmware Updates
- Product Training and Education
- Parts and Accessories Replacement
Our team is available to help you with any questions or concerns about your automotive MAP sensor. We strive to provide the highest quality service and support for all of our customers.
Packing and Shipping:
Automotive MAP sensor Packaging and Shipping:
- Packaging: Anti-static bag with foam padding
- Shipping: Use a reliable, traceable shipping carrier with insurance
FAQ:
- Q. What is an automotive MAP sensor?
- A. A Manifold Absolute Pressure (MAP) sensor is an electronic device designed to measure air pressure in an automotive engine's intake manifold.
- Q. What brand is the Oetex automotive MAP sensor?
- A. Oetex is the brand of the automotive MAP sensor.
- Q. Is the Oetex automotive MAP sensor certified?
- A. Yes, the Oetex automotive MAP sensor is certified by ISO9001.
- Q. How does the Oetex automotive MAP sensor work?
- A. The Oetex automotive MAP sensor measures the air pressure in the intake manifold and sends the data to the engine's computer. The computer then uses the data to adjust the fuel-air ratio, idle speed, and ignition timing.
- Q. What type of engine is the Oetex automotive MAP sensor compatible with?
- A. The Oetex automotive MAP sensor is compatible with most gasoline and diesel engines.
