Bosch 0281002576 Manifold Absolute Pressure MAP Sensor 4 Bar

Product Description:

A Manifold Absolute Pressure Sensor (MAP) is an important component used in a car's engine. It functions to measure the amount of pressure in the inlet manifold and send information to the Engine Control Unit (ECU). This data helps the ECU to calculate air density and decide the air-fuel mixture for the combustion. The MAP sensor is also used to determine engine load, fuel injection pulse, and tweak ignition timing.

Here are some other roles that a MAP sensor plays:

• It can be used to detect issues regarding the throttle's performance.
• It can also be used to research for any vacuum leaks within the inlet manifold.
• By analyzing the MAP sensor signal along with the engine speed and Intake Air Temperature (IAT) data, the output can be converted into air mass measurement.
• In vehicles with an On-Board Diagnostics system (OBD-II), the MAP signal is commonly used to see if the Exhaust Gas Recirculation (EGR) valve is operating properly. It can also be used as an alternative to the Mass Air Flow (MAF) sensor, which measures air density and volume, to look into the EGR valve.

Generally, MAP sensor malfunctions happen due to contamination, clogging, or its electronics being heated up by the engine. Other signs of the pressure sensor wearing out include engine difficulty starting, detonation or misfire, high fuel consumption, lack of engine power, and a "Check Engine Light" coming up on the dashboard with a P0105 code stored.

Features:

• Product Name: Manifold Absolute Pressure Sensor
• Supply Voltage: 3.3V-5V
• Interface Type: Analog
• Pressure Range: 0-1.2MPa
• Material: Stainless Steel

Technical Parameters:

Applications:

The manifold absolute pressure sensor from Oetex is an ideal solution for a wide range of applications. It is certified with ISO9001 and offers reliable performance in a variety of conditions. This sensor can be used with a variety of vehicles, including cars, trucks, and even motorbikes. It is made from stainless steel and has an operating voltage of 5V. The supply voltage ranges from 3.3V to 5V, and the size of the sensor is 3.2 X 2.3 X 1.2cm. The output type is an analog voltage. The sensor is highly accurate and can measure the manifold absolute pressure in a wide range of vehicles. The minimum order quantity is 10 pieces, and the packaging can be either neutral or customised to the customer’s request. Delivery time is 15-30 days, and payment terms include Paypal, Western Union, Bank T/T, and L/C. The monthly supply ability for this sensor is 5000 pieces.

Customization:

Support and Services:

We provide technical support and services for Manifold Absolute Pressure Sensor. Our team of experts are available to answer your queries and provide assistance as needed. We provide free software updates to keep your system running smoothly, as well as troubleshooting and diagnostic services. Additionally, we offer a warranty and repair services in the event that your device malfunctions.

Packing and Shipping:

Packaging and Shipping for Manifold Absolute Pressure Sensor:

• The product will be shipped in an anti-static bag.
• It will be packed in a cardboard box with protective cushioning material.
• The box will be sealed with adhesive tape.
• It will be shipped in a secure envelope via a reputable courier.

FAQ:

Q1: What is the brand name of the manifold absolute pressure sensor?

A1: The brand name of the manifold absolute pressure sensor is Oetex.

Q2: What is the model number of the manifold absolute pressure sensor?

A2: The model number of the manifold absolute pressure sensor is China.

Q3: Does the manifold absolute pressure sensor have ISO9001 certification?

A3: Yes, the manifold absolute pressure sensor has ISO9001 certification.

Q4: What is the minimum order quantity for the manifold absolute pressure sensor?

A4: The minimum order quantity for the manifold absolute pressure sensor is 10.

Q5: What is the delivery time for manifold absolute pressure sensor?

A5: The delivery time for manifold absolute pressure sensor is 15-30 days.
