2Ms Response Time Car MAP Sensor 0.5-4.5V Output Signal Engine Map Sensor
3-Pin Automotive MAP Sensor with 0.5-4.5V Output Signal and 2 Ms Response Time
Product Description:
A manifold absolute pressure (MAP) sensor measures the pressure in the intake manifold. Usually located next to or on the throttle body, it transmits information about the intake manifold pressure to the Engine Control Unit (ECU). With this data, the ECU can work out the air density and accordingly adjust the air-fuel mixture amount for combustion. Besides, the ECU can also use this data to measure engine load, control the fuel injection pulse and adjust the ignition timing.
A MAP sensor also provides information for diagnosing potential issues with the throttle, detecting vacuum leak in the intake manifold, as well as converting the MAP signal into air mass data with the help of engine speed and Intake Air Temperature (IAT) sensor. Moreover, it is also used in OBD II cars to assess if the Exhaust Gas Recirculation or EGR valve is operational. When paired with a mass airflow sensor (measuring air density and volume)in some vehicles, the MAP sensor can be used as a backup to monitor the performance of the EGR valve.
Common causes of a failing MAP sensor include contamination, clogging and damages from exposure in the engine compartment. Symptoms of it may include lack of engine start or power, detonation or misfires, high fuel consumption, as well as Check Engine Light.
Features:
- Product Name: Automotive MAP Sensor
- Housing Material: Stainless Steel
- Pressure Range: 0-5 Bar
- Operating Temperature: -40 To 125°C
- Manufacturer: XYZ
- Protection Level: IP67
- Function: Automotive Boost Pressure Sensor, Engine Management Pressure Sensor, Automotive Vacuum Pressure Sensor, Automotive Vacuum Sensor, Automotive Pressure Sensor
Technical Parameters:
| Attribute | Value |
|---|---|
| Intake Manifold Pressure Sensor | Yes |
| Manifold Absolute Pressure Sensor | Yes |
| Manifold Air Pressure Sensor | Yes |
| Power Supply | 5 V |
| Warranty | 2 Years |
| Operating Temperature | -40 To 125°C |
| Manufacturer | XYZ |
| Dimensions | 30 X 18 X 10 Mm |
| Accuracy | ±0.5% |
| Pressure Range | 0-5 Bar |
| Response Time | 2 Ms |
| Connector Type | 3-pin |
| Protection Level | IP67 |
Applications:
The Oetex Automotive MAP Sensor is an ideal engine management pressure sensor for automotive applications. With a certification of ISO9001, the sensor is guaranteed to be of the highest quality and comes with a two-year warranty. The sensor is IP67 rated for dust and water protection, and features a 3-pin connector with a stainless steel housing. The sensor is powered by a 5 VDC power supply and is designed to measure boost pressure in engine management systems. This sophisticated MAP Sensor helps automotive engineers to accurately monitor the performance of their vehicles, providing reliable, real-time data. With its robust construction and reliable performance, the Oetex Automotive MAP Sensor is the perfect choice for any automotive application.
Customization:
Oetex Automotive MAP Sensor is designed for automotive boost pressure sensing applications which can accurately measure manifold air pressure. It is an ideal choice for intake manifold pressure sensing. It offers great accuracy and response time with certification of ISO9001 and 2-year warranty.
- Brand Name: Oetex
- Certification: ISO9001
- Warranty: 2 Years
- Response Time: 2 Ms
- Accuracy: ±0.5%
- Output Signal: 0.5-4.5 V
- Weight: 20 G
Support and Services:
Automotive MAP sensor technical support and service includes:
- Troubleshooting support for automotive MAP sensors.
- Installation and calibration assistance.
- Software and firmware updates.
- Replacement parts and accessories.
- Product warranty information.
Packing and Shipping:
- The product will be securely packed in a custom-made box and sealed with a security seal.
- The package will be shipped with a reliable carrier such as FedEx, UPS, or DHL.
- The shipment will be tracked and monitored to ensure safe delivery.
FAQ:
- Q: What is the brand name of the automotive MAP sensor?
A: The brand name of the automotive MAP sensor is Oetex. - Q: Does the automotive MAP sensor have a certification?
A: Yes, the automotive MAP sensor has a certification of ISO9001. - Q: What is the working pressure range for the automotive MAP sensor?
A: The working pressure range for the automotive MAP sensor is 0~1.2bar. - Q: What is the working voltage range for the automotive MAP sensor?
A: The working voltage range for the automotive MAP sensor is 4.5~18V. - Q: What is the response time for the automotive MAP sensor?
A: The response time for the automotive MAP sensor is less than 0.2s.
