Single Phase AC Mobile EV Charger 3kW Mobile Ev Charging Units
3kW Portable Box Single-Phase AC 13A EV Charging
Short Description:
EN Plus launched portable intelligent EV charger, meet the EV owners’ functional demand of portable and plug-and-play, make charging your electric vehicle as easy as charging your mobile phone.
Key Features:
-
Power: 3kW
-
Output Current: 13A
-
Power Cord Plug: Schuko(can be customized)
-
Charging Outlet: One Type 2 charging connector (can be customized)
-
Plug-and-play
-
Protection Grade: IP65
-
Warranty: 2 years
Product Features
Easy Operation
Simple and portable.
Charge your EV wherever and whenever.
Plug and Play
Easy operation, plug and play.
Charging EV just like charging your mobile phone
Friendly Interface
Simple HMI with LED indictors.
Charging status identification.
Robust Structure
Anti-corrosion and weather proof.
IP65 protection grade for outdoor use stably.
Secure and Safe
Current leakage protection to ensure safety.
Over-temperature protection to secure reliability.
Work Temperature
Work at -30°C~+50°C
Relative humidity ≤ 95% can work normally
Specification
| Specification | Model | AC3500-DE-00 |
|
AC Nominal Input
|
Phases/Lines | 1 phase + netural+ PE |
| Voltage | 230V±10% | |
| Frequency | 50/60Hz | |
|
AC Nominal Output
|
Voltage | 230V±10% |
| Current | 13A | |
| Power | 3kW | |
|
Structure Design
|
Housing Material | Plastic PC940 |
| LED Indicator | 4 indicators | |
| Power Cord Plug | Schuko | |
| Charging Outlet | One charging gun (Type 2) | |
| Cable Length | 4M | |
|
Environmental Index
|
Operating Temperature | - 30~ + 50℃ |
| Working Humidity | 5%~95% without condensation | |
| Working Altitude | ＜2000M | |
| Protection Grade | IP65 | |
| Application Site | Indoor/Outdoor | |
| Cooling Method | Natural cooling | |
|
Security Protection
|
Multiple Protection | Over/Under voltage protection,Overload protection,Short circuit protection,Current leakage protection,Grounding protection,Surge protection,Over/Under temperature protection |
| MTBF | 100,000 hours | |
| Safety Standard | IEC 61851-1:2017,IEC 62196-2:2016 | |
| Warranty | 2 years | |
|
Package Information
|
Product Dimension | 195*74*47MM |
| Package Dimension | 360*295*155MM | |
| Net Weight | 1.5KG | |
| Gross Weight | 2,4KG | |
| External Packing | Carton |
