Automatic PET Bottles Non Carbonated Drink Kombucha Filling Machine
Automatic PET bottles Non-Carbonated Drink Kombucha Filling Machine
Applications:
The machine is mainly applied for the filling of beverage. Integrating with washing, filling and sealing, it realizes full automation in the whole process, suitable for polyester bottle and plastic bottle filling of mineral water and purified water. The bottle types applicable for various parts are easily, conveniently and rapidly adjustable. It adopts new micro-negative pressure filling, stable and reliable. Compared with the machines of the same specification, the benefit of this machine is larger.
Product Paramenters:
| Model | CGF32-32-10 |
| Application | Spring water / mineral water / pure water / non-gas wine drink and so on |
| No. of Rinsing/Filling/Capping | 32-32-10 |
| Production Capacity(500ml) | 16000-17000BPH |
| Filling precision | ≤±5mm(liquid level) |
| User Ambient Conditions | Temperature:10~40℃; Humidity: No dew |
| Suitable bottle specification |
Volume=100-2000ml Diameter φ=50-100mm Bottle height H=150 ~340mm |
| Bottle type | Plastic bottle / PET Bottle |
| Bottle neck/Cap Style | Plastic Screw Cap φ=20-50mm |
| Machine material | Food stage SS304 OR SS316 |
| Air source pressure | 0.5~0.6Mpa |
| Filling way/principle | Gravity filling method |
| Control system | SIMENS PLC+ TOUCH SCREEN |
| Features | No Bottle No Filling No Bottle No Capping |
| Main Power | 5.5kw |
| Power Supply | Voltage:220V~480V,3phase; Frequency:50HZ/60HZ or your requirement |
| Overall dimensions (mm) | 3800*2800*2600 |
| Weight (kg) | 6500 |
| All machines could be customized , we could design and produce machines according to your request. | |
Features :
This machine works harmoniously with air-conveyor belt, It holds the bottles by the neck, thus, reducing the possibility of bottles falling over during conveying process.
This machine is used to fill juice and noncarbonated drink into pet bottle and with screw caps capping
function.
This machine integrated three function:
1. Rinse the empty pet bottle, 2. filling the rinsed bottles, 3. capping the filled bottles
Rinser Station:
- All 304 stainless steel rinser heads, water spray style inject design, more save water consumption & more clean
- 304 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing
- 304 stainless steel washing pumps
Filler station
High precision filling nozzle, PLC variable signal control, ensure high filling precision & filling smoothly & steadily,
All 304 stainless steel contact parts &
liquid tank, fine polish, easy to clean
No bottle no filling
Capper Station
- Place & capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping
- All 304stainless steel construction
- No bottle no capping
Electric Part & Safe Device & Automation:
- When accident system automatic stop & alarm
- Emergency switch when accident
- PLC , Touch-screen Control Panel & inverter
- Food Grade 304 stainless steel rinsing pump, reliable & sanitary
Machine Base & Machine Construction:
- 304 stainless steel frame
- Tempering Glass window, Clear & no odor
- Excellent start wheel design, easy change over parts
- Machine Base with anti-rust process, ensure the forever antirust
- All seal where liquid may Leakage & base neck come with rubber, water proof
- Manual lubrication system
