Durable Ore Crushing Machine 30-60 TPH Output For Small Production Line

Price Negotiable

Price: USD 64,726.03-76,209.68 one set

MOQ: 1 set

Delivery Time: 30-90 days

Brand: BENO

Product Description

Ore Crushing Roll Crusher Machine 30-60 TPH Output For Small Production Line

Product Description

1. The motor required for the equipment is two motors with power of 18.5 kW.

2. The toothed roller of this Roll Crusher Machine is made of manganese chromium alloy, which is very wear-resistant and durable.

3. The tooth roller of this Roll Crusher Machine is 1500 mm in length and 500 mm in diameter.

4. The production capacity of this Roll Crusher Machine is 30-60 tons per hour.

5. The weight of this equipment is 10.5 tons.

Equipment Advantages

1. Light weight, easy to transport.

2. The motor power is small, saving energy consumption.

3. Suitable for small crushing production line.

Technical Reference Data

Model	Diameter of roller (mm)	Length of roller (mm)	Maximum side length of feeding material (mm)	Grain size of discharging material(mm)	Production capacity (t/h)	Power (kw)	Soft connection weight (t)	Direct connection weight (t)
XCMD500	500	1000	≤50	≤10-25	20-50	15*2	9.5	8.2
		1500			30-60	18.5*2	11.8	10.5
		2000			40-70	22*2	14.5	12.8
		2500			50-80	30*2	18	16.3
XCMD650	650	1000	≤60	≤10-25	30-80	45*2	12.3	10.5
		1500			50-100	55*2	18.5	16
		2000			60-160	75*2	23	21
		2500			75-220	90*2	28	25
XCMD750	750	1000	≤70	≤10-30	50-150	55*2	23	21
		1500			80-180	75*2	26.5	24.5
		2000			100-200	90*2	30	27.2
		2500			120-250	110*2	33.8	30.8
XCMD850	850	1000	≤75	≤10-30	100-220	75*2	26	23.5
		1500			200-400	90*2	31.5	28.5
		2000			300-500	110*2	36	33
		2500			350-650	132*2	39	36
XCMD1000	1000	1000	≤100	≤10-30	250-450	90*2	46.8	41
		1500			350-550	110*2	52	46.2
		2000			500-700	132*2	58	52.5
		2500			650-800	160*2	65	60
XCMD1200	1200	1500	≤120	≤10-30	350-900	160*2	81	73
		2000			450-1000	185*2	93	85
		2500			600-1200	220*2	106	98
