150 TPH 220 TPH Heavy Duty Stone Crusher Two Roll High Throughput

Price Negotiable

Price: USD 79,452.05-93,548.39 one set

MOQ: 1 set

Delivery Time: 30-90 days

Brand: BENO

Product Description

XCMD500 * 2000 Double Roller Crusher 150-220 TPH Small Broken Line

Product Description

Double Roller Crusher is our high-end customizable product.

Among the crushing plants with the same output, the power consumption of Double Roller Crusher is lower, while ensuring high throughput. Due to the three-point crushing method, it can ensure the regular shape of the crushed material like a round body, which will not make cracks inside the material and will not destroy the strength and nature of the material itself, and improve the efficiency of the subsequent material use.

Equipment Features

1. Patented special tooth type

2. Three-point crushing method (cutting, stretching)

3. Low energy consumption and high throughput

4. Quickly replaceable wear parts tooth rollers

5. For the crushing of highly abrasive and viscous materials

6. Product size change by adjusting the gap between the crushing bar and the rollers

7. Product size change by adjusting the axis distance (secondary and tertiary crushers)

8. Mechanical coupling between gearbox and crushing rolls

9. V-belt connection between rolls and gearbox hydraulic coupling

Technical Reference Data

Model	Diameter of roller (mm)	Length of roller (mm)	Maximum side length of feeding material (mm)	Grain size of discharging material(mm)	Production capacity (t/h)	Power (kw)	Soft connection weight (t)	Direct connection weight (t)
XCMD500	500	1000	≤100	≤30-60	50-120	37*2	9.5	8.2
		1500			100-180	45*2	11.8	10.5
		2000			150-220	90*2	14.5	12.8
		2500			200-300	110*2	18	16.3
XCMD650	650	1000	≤120	≤30-60	50-130	45*2	12.3	10.5
		1500			100-255	55*2	18.5	16
		2000			200-350	75*2	23	21
		2500			350-450	90*2	28	25
XCMD750	750	1000	≤140	≤40-70	150-250	55*2	23	21
		1500			200-350	75*2	26.5	24.5
		2000			250-450	90*2	30	27.2
		2500			350-550	110*2	33.8	30.8
XCMD850	850	1000	≤160	≤40-70	150-300	75*2	26	23.5
		1500			200-400	90*2	31.5	28.5
		2000			300-500	110*2	36	33
		2500			350-650	132*2	39	36
XCMD1000	1000	1000	≤220	≤40-80	250-450	90*2	46.8	41
		1500			350-550	110*2	52	46.2
		2000			500-700	132*2	58	52.5
		2500			650-800	160*2	65	60
XCMD1200	1200	1500	≤250	≤40-90	650-900	160*2	81	73
		2000			750-1100	185*2	93	85
		2500			900-1500	220*2	106	98
