220V 0.4L High Efficiency Lab Ball Mill Planetary Laboratory Grinding Equipment

Price Negotiable

Price: Negotiable

MOQ: 1 Set

Delivery Time: 3-7 Days

Brand: Kingda

Product Description

0.2L / 0.5L / 1L / 2L Lab Horizontal Ball Mill Full Automatic

0.4L Ceramic Ball Mill 220V Desktop Laboratory Grinding Equipment

Product Overview

The Vertical Planetary Ball Mill is an essential device for high-tech materials mixing, fine grinding, sample preparation, new product development, and small batch production
With compact design, high efficiency, low noise, and versatile features, this mill is ideal for research institutions, universities, and enterprise laboratories requiring precision in sample preparation
Features four ball grinding tanks installed on one turnplate that creates planetary movements for high-speed grinding and mixing
Capable of processing various materials and granularities using dry or wet methods, achieving minimum particle sizes down to 0.1 micron
Widely used in Geology, Mining, Metallurgy, Electronics, Construction Materials, Ceramics, Chemical Engineering, Light Industry, Medicine, and Environmental Protection
Designed with comprehensive safety features and stable 220V power supply performance

Applications

Materials Research and Development: Crucial for mixing, fine grinding, and new product development of high-tech materials, enabling rapid production of samples with high purity and precise particle size
Laboratory Sample Preparation: Ideal for universities, research institutions, and enterprise laboratories, capable of processing four samples simultaneously to enhance experimental efficiency

Technical Specifications

Drive Mode	gear drive / belt drive
Operation Mode	2 / 4 grinding tanks working together
Maximum Loading Capacity	2/3 of the capacity of milling tank
Feeding Granularity	soil material ≤10mm, other materials ≤3mm
Output Granularity	Minimum 0.1um
Rotational Speed Ratio	1:2 (0.4L,2L,4L); 1:1.5(12L,20L)
Rotation Speed	0.4L: 0~600 rounds/min; 2L: 0~580 rounds/min; 4L: 0~530 rounds/min; 20L: 0-280 rounds/min
Speed Regulation Mode	Variable-frequency control and program-control stepless speed regulation; manual or automatic timing; forward or reverse rotation
Max. Continuous Operating Time (full-load)	72 hours

Planetary Ball Mill Models

Model	Specification	Capacity Range	Quantity
KD-XQM-0.4L	0.4L	50-100ml	4 mill tanks
KD-XQM-1L	1L	50-250ml	4 mill tanks
KD-XQM-2L	2L	560-500ml	4 mill tanks
KD-XQM-4L	4L	50-1000ml	4 mill tanks
KD-XQM-8L	8L	0.5-2L	4 mill tanks
KD-XQM-12L	12L	1-3L	4 mill tanks
KD-XQM-16L	16L	1-4L	4 mill tanks

Key Features

Stable gear transmission ensures consistent and repeatable experimental results
Planetary movement principle delivers high speed, energy efficiency, and fine particle size reduction
Simultaneous processing of four different powder samples
Frequency converter control with under-voltage and over-current protection
Programmable operation modes including timing, directional control, and rotation patterns
Low center of gravity, stable performance, compact structure, and easy operation
Integrated safety switch prevents operation when safety cover is open

Packaging & Shipping

Packaging Type: PE Form + Cartons / Wooden cases; Custom packaging available

Port: Shanghai Port, Guangzhou Port, Tianjin Port, Qingdao port

Delivery Time: Within 3-7 working days from payment receipt

Manufacturing Facility

Frequently Asked Questions

Q: What is the size in your products?

A: The minimum type is 0.4L planetary ball mill Model XQM-0.4A (53×30×34cm, 26kg). Models available from 0.2L to 100L capacity.

Q: What is your terms of delivery?

A: FOB, CFR, CIF.

Q: Can you accept small quantity sample order before production?

A: Yes, samples available for testing with customer covering courier costs.

Q: What is your production time?

A: Generally 3-7 days after receiving advance payment, depending on order specifics.

Q: What is your terms of payment?

A: T/T 30% deposit, 70% balance against B/L copy, or 100% L/C at sight.

Q: What is the working principle of planetary ball mill?
