Lab Roller Ball Mill Machine with 4-5L Mill Jar, 1000 Mesh Output, and 1-7 kg/h Capacity for Laboratory Research
Price:
Negotiable
MOQ:
1 set
Delivery Time:
15Day
Brand:
KINGDA
Product Description
Lab Roller Ball Mill Machine KDGQM4-15
Factory Sale Lab Jar Roller Mill/Jar Ball Mill Grinding With Drum/Ball Mill Jar For Roller Ball Mill Laboratory
In the realm of scientific exploration and experimentation, the quest for precise and efficient laboratory equipment is unending. Researchers, scientists, and engineers constantly seek innovative tools that can enhance their processes, streamline workflows, and produce reliable results. One such groundbreaking device that has revolutionized the field of materials science and sample preparation is the Lab Jar Roller Mill Machine.
With its simplistic yet robust design, the Lab Jar Roller Mill Machine consists of a series of rotating jars or containers mounted on a horizontal roller. These jars, made of high-quality materials such as stainless steel or ceramic, are precisely aligned and spaced to ensure efficient milling. The roller mechanism imparts both rotational and lateral movement to the jars, resulting in a cascading motion that promotes effective grinding and mixing of the contents.
One of the key advantages of the Lab Jar Roller Mill Machine is its versatility. It can accommodate a diverse range of sample sizes and types, making it an indispensable tool for various research fields. Whether researchers need to pulverize solid materials, blend powders, disperse pigments, or obtain homogeneous mixtures, this machine offers exceptional control over particle size reduction and material blending, enabling reproducible and accurate results.
Working Principle
Commencing operation, the grinding media and materials enclosed within the cylinder rotate to a predetermined height. Guided by gravity, they then descend from the inner walls of the tube. Material crushing occurs through a blend of grinding media impact, friction, and shearing from rolling and sliding movements. This optimized procedure not only boosts efficiency, thus saving time and labor, but also guarantees smooth and effortless operation.
Specifications
| Category | Model No. | Power Supply | Rotate Speed | Max Load Per Jar | Dimensions & Net Weight | |
|---|---|---|---|---|---|---|
| 2 Work Positions | GQM-2-5 | 220V-50Hz or 60Hz/0.75kw | 50-410 rpm | 35KGS | 950*480*685mm 59KGS | |
| GQM-2-15 | 220V-50Hz or 60Hz/1.1kw | 40-365 rpm | 80KGS | 1130*550*690mm 80KGS | ||
| GQM-2-20 | 220V-50Hz or 60Hz/1.5kw | 40-340 rpm | 120KGS | 1350*650*690mm 92KGS | ||
| 4 Work Positions | GQM-4-5 Single layer | 220V-50Hz or 60Hz/0.75kw | 50-410 rpm | 35KGS | 950*660*690mm 70KGS | |
| GQM-4-5 Double layer | 220V-50Hz or 60Hz/0.75kw | 50-410 rpm | 35KGS | 950*480*870mm 92KGS | ||
| GQM-4-15 | 220V-50Hz or 60Hz/1.5kw | 40-365 rpm | 80KGS | 1130*800*690mm 95KGS | ||
| GQM-4-20 | 380V-50Hz or 60Hz/2.2kw | 40-340 rpm | 120KGS | 1350*820*690mm 122KGS | ||
| 8 Work Positions | GQM-8-5 | 220V-50Hz or 60Hz/1.5kw | 50-410 rpm | 35KGS | 950*660*960mm 106KGS | |
| GQM-8-15 | 380V-50Hz or 60Hz/2.2kw | 40-365 rpm | 80KGS | 1130*800*960mm 152KGS |
Features
- Multiple sample materials can be ground simultaneously
- Offers both intermittent and continuous operation modes
- Users can adjust timing to suit their requirements
Accessories of Grinding Pots & Balls
Available grinding jars in full sizes:
Zirconia ball mill jar, alumina ball mill jar, Agate ball mill jar, Tungsten ball mill, hard metal mill jar and etc.
Package & Shipping
Package Type
PE Form + Cartons / Wooden cases; Can be dispatched according to customer's requirement
Port
Shanghai Port, Guangzhou Port, Tianjin Port, Qingdao port
Delivery Time
Within 3-7 working days from the date of payment receipt
Factory
Frequently Asked Questions
1. What are the roll mill jars available in your products?
Our available roll mill jars are alumina / zirconia ceramic, nylon, stainless steel, tungsten carbide, PTFE, polyurethane and so on.
2. What is your terms of delivery?
FOB, CFR, CIF.
3. Can you accept small quantity sample order before production?
Yes, we can offer sample for your testing first before production, but the customers have to pay the courier cost.
4. What is your production time?
Generally, it will take 3-15 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
5. What is your terms of payment?
T/T 30% as deposit, 70% balance against the copy of original B/L. Or 100% L/C at sight. We'll show you the photos of the products and the copy of original B/L before you pay the balance.
Our Service
- We can produce other grinding balls as your need
- We test all the goods before delivery
- We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from
- If you have any questions, please contact with us without any hesitation, we will reply you in 2 hours
About Kingda
1. HUNAN KINGDA CERAMIC TECHNOLOGY CO.,LTD is a manufacturer of the Grinding Media Ball, Grinding Jars, Zirconium Dioxide, Zirconia structures, etc.
2. "Quality Is in the First Position forever", we have gained a high reputation and good recognition from a lot of domestic and overseas customers such as University of Oxford, Loughborough University, Peking University, Tsinghua University, etc.
3. We promise that we would make great efforts to provide high quality grinding products and best services for all customers in the coming years.
4. Nowadays, KINGDA CERAMIC MATERIALS has gained great reputation from our business partners. We will continue to contribute the best to realize mutual benefit and sustainability.
5. We appreciate your interest and support in the efforts and passion of KINGDA CERAMIC, the company of Human Technology.
