99.9% Pure Copper Sheet ASTM H63 C27200 CuZn37 CA108 Brass Sheet Brass Plate
Price:
Negotiable
MOQ:
1 TON
Delivery Time:
10 days
Brand:
Antai
Product Description
99.9% Pure Copper Sheet ASTM H63 C27200 CuZn37 CA108 Brass Sheet Brass Plate
| Model Number | H59,H62-H96, etc. |
| Application | Can make all kinds of deep drawing and bending manufacturing force parts, such as pins, rivets, washers, nuts, conduits, barometer, screen, radiator parts and so on |
| Width | 10~2000 mm or as required |
| Cu (Min) | 59% or as required |
| Ultimate Strength (≥ MPa) | 220--400 or as required |
| Elongation (≥ %) | 20-40 or as required |
| Processing Service | Bending, Welding, Decoiling, Cutting, Punching |
| Cu (Min) | 62% or as required |
| OEM | Accept |
| Surface | Bright, color coated, polished |
| Model Number | C2680, C2800, C3604,C2600 or as required |
| Width | 500-2000mm, or as required |
| Standard | GB, ASTM, UNS, SAE, DIN, SUS, JIS |
| Brass Alloy | Tensile Strength (N/mm) | Elongation(%) | Hardness (HV) | ||||||||
| Soft | 1/2H | H | Soft | 1/2H | H | Soft | 1/4H | 1/2H | 3/4H | H | |
| C2100 (H96) | ≥205 | 270-345 | ≥280 | ≥33 | ≥18 | — | ≤65 | 65~80 | 80-100 | — | ≥100 |
| C2200 (H90) | ≥225 | 295-365 | ≥320 | ≥35 | ≥20 | — | ≤70 | 70~95 | 95-120 | — | ≥120 |
| C2300 (H85) | ≥245 | 310-385 | ≥340 | ≥40 | ≥23 | — | ≤70 | 70~95 | 95-120 | — | ≥120 |
| C2400 (H80) | ≥255 | 320-405 | ≥375 | ≥44 | ≥25 | — | ≤80 | 75-105 | 100-130 | — | ≥125 |
| C2600 (H70) | ≥295 | 370-440 | 430-510 | ≥5 | ≥30 | ≥14 | ≤90 | 90-105 | 105-130 | 130-145 | 145-160 |
| C2680 (H65) | ≥295 | 370-440 | 430-510 | ≥45 | ≥30 | ≥14 | ≤90 | 90-105 | 105-130 | 130-145 | 145-160 |
| C2720 (H63) | ≥295 | 370-440 | 430-510 | ≥45 | ≥30 | ≥14 | ≤90 | 90-105 | 105-130 | 130-145 | 145-160 |
| C2800 (H62) | ≥320 | 410-490 | ≥450 | ≥35 | ≥15 | — | — | 85-105 | 105-130 | — | ≥130 |
