Electric Metal Surface Precision Surface Grinder 230mm For Construction
Price:
USD 2000-50500
MOQ:
1 set
Delivery Time:
30-45days
Product Description
Electric Metal Surface Cylindrical Grinding Machine
Company Info.
Basic Info.
Model NO.
M7140Ax2200
Working Style
High-speed universal
Disc Diameter
230mm
Variable Speed
With Variable Speed
Table Size(Wxl)
400X1600(Mm)
Max. Machining Dimension(Wxl)
400X1600(Mm)
Longitudinal Moving Speed of Worktable
5-25m/Min
T-Slot Number X W
3X18(Mm)
Transport Package
Wood Case or Carton
Specification
CE ISO
Trademark
GNG MACHINE
Origin
China
HS Code
84595900
Production Capacity
500 Sets/Month
Product Description
M71 wheel head moving surface grinder M7140Ax2200
| table size(WxL) | mm | 400x2200 | |
| max. machining dimension(WxL) | mm | 400x2200 | |
| max. distance between spindle center line and worktable surface | mm | 600 | |
| longitudinal moving speed of worktable | m/min | 5-25 | |
| T-slot number x W | mm | 3x18 | |
| wheel head cross moving | continuous feed speed | m/min | 0.5-4.5 |
| intermittent feed speed | mm/t | 3-30 | |
| hand wheel feed | mm/gra | 0.02 | |
| wheel head vertical moving | rapid speed | mm/min | 400 |
| feed of handwheel | mm/gra | 0.01 | |
| wheel head motor | power | kw | 7.5 |
| rotation speed | rpm | 1440 | |
| total power | kw | 13.5 | |
| max. loading capacity of worktable with chuck | kg | 1380 | |
machine dimension(LxWxH):674x182x223(cm)
package dimensions(LxWxH):680x220x233(cm)
machine weight:8.5T
