Chemical Resistant Composite Flexible Hose Multiple Durable Lightweight

Price Negotiable

Price: 10

MOQ: 1

Delivery Time: 5-8days

Brand: Jiubei

Product Description

Chemical-Resistant Composite Flexible Hose for Multiple Applications Durable Lightweight

Aproductdevelopedspecificallyforconveyingpaintand coatings, with resistance to solventsAgent,wear-resistantandexcellentantioxidantproperties,with a conductive design.

GGP is applicable to all fuel oil products.PGP SSP SGT is suitable for corrosive chemical liquidstransportation.
Teflon is not corroded byany concentration of acid or alkali, and has the best The resistance to chemical corrosion.
Users who require lighter hoses, metal inside the hoseThe wire can be made of aluminum alloy material.

Type	GGP	PGP	SSP	SGT
Inner ringsteel wire	Hot dip galvanized steel wire	Polypropylene Coated steel wire	stainless steel	stainlesssteel
Outer ring steel wire	Hot dip galvanized steel wire	Hot dip galvanized steel wire	stainless steel	Hot dip galvanized steel wire
Inner layer material	Polypropylene	Polypropylene	Polypropylene	Teflon
Applicable temperature:-30'C~+100'c Working pressure:150psi,220psi
Size:1inch~4inch

Technical Parameters

I.D (MM/IN)	Max. WP. (psi/Mpa)	Blasting Pressure (psi/Mpa)	Reference Weight (kg/m)	Bending Radius (mm)
25/1	150/1.03	600/4.2	0.9	100
38/1.5	150/1.03	600/4.2	1.5	110
51/2	150/1.03	600/4.2	1.8	125
65/2.5	150/1.03	600/4.2	2.5	150
76/3	150/1.03	600/4.2	2.3	200
100/4	150/1.03	600/4.2	9.9	500
150/6	150/1.03	880/6.06	1.2	100
25/1	220/1.516	880/6.06	2.0	120
38/1.5	220/1.516	880/6.06	2.2	180
51/2	220/1.516	880/6.06	2.5	260
65/2.5	220/1.516	880/6.06	3.0	260
76/3	220/1.516	880/6.06	5.0	400
100/4	220/1.516	880/6.06	14	600
152/6	220/1.516	880/6.06	22	800
202/8	220/1.516	880/6.06	27	1100
252/10	220/1.516	880/6.06
