201 321 310 Stainless Steel Flat Bar 10mm TUV Solid Steel Bar Polished
Polished 201 304 316 409 410 420 430 321 310 Stainless Steel Flat Bar Rod 10mm Solid Steel Bar Sizes
Stainless steel flat steel is rectangular steel with slightly pure edge. Stainless steel flat steel can be semi-finished steel. There are cold drawn polished stainless steel flat steel and hot-rolled acid white sandblasted stainless steel flat steel.
| Grade | 301, 304, 304L, 309S, 310S, 316, 316L, 317, 317L, 321, 201, 202, 329, 347, 347H, 410, 420, 430, etc. |
| Standard | JIS AISI ASTM TUV DIN BV SUS etc. |
| Length | 3-12m or as your request |
| Thickness | 2-100mm or as your request |
| Width | 10-500mm or as your request |
| Surface Treatment | acid pickling/Mirror polish/Color coating/Brushed/Common polishing |
| Applications | Decorative /industrial/building material |
| Trade Terms | EXW, FOB, CFR, CIF |
| Delivery time | Shipped in 7-15 days after payment |
| Package | Standard sea-worthy package or as required |
| Seaworthy Packing | 20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM |
| 40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM | |
| 40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM |
| Chemical Properties of Frequently-used Stainless Steel Material Grade | |||||||||||
| UNS | ASTM | EN | JIS | C% | Mn% | P% | S% | Si% | Cr% | Ni% | Mo% |
| S20100 | 201 | 1.4372 | SUS201 | ≤0.15 | 5.5-7.5 | ≤0.06 | ≤0.03 | ≤1.00 | 16.0-18.0 | 3.5-5.5 | - |
| S20200 | 202 | 1.4373 | SUS202 | ≤0.15 | 7.5-10.0 | ≤0.06 | ≤0.03 | ≤1.00 | 17.0-19.0 | 4.0-6.0 | - |
| S30100 | 301 | 1.4319 | SUS301 | ≤0.15 | ≤2.00 | ≤0.045 | ≤0.03 | ≤1.00 | 16.0-18.0 | 6.0-8.0 | - |
| S30400 | 304 | 1.4301 | SUS304 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 8.0-10.5 | - |
| S30403 | 304L | 1.4306 | SUS304L | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 8.0-12.0 | - |
| S30908 | 309S | 1.4833 | SUS309S | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 22.0-24.0 | 12.0-15.0 | - |
Stainless steel flat steel can form various stress components according to different structural needs, and can also be used as connectors between components. It is widely used in various building structures and engineering structures, such as house beams, bridges, transmission towers, hoisting and transportation machinery, ships, industrial furnaces, reaction towers, container racks and warehouse shelves.
Stainless steel flat steel is used as bridge, house frame, fence, power transmission ship, vehicle, etc. in construction engineering. The raw material billet for the production of stainless steel flat steel is low-carbon square billet, and the finished stainless steel flat steel is delivered in hot-rolled forming, cold-rolled or hot-rolled state. During the transaction, the side width and side thickness of stainless steel flat steel shall be fully filled in the contract and other documents, as well as other main process matters, such as annealing, solid solution, etc.
