High Power Motorcycle Electrical Connector 250A 1000V Waterproof
250A 1000V New Energy Storage Butadiene Rubber High Power Waterproof Connector
1. product description
This is high power waterproof connector,the material is Rubber and PVC plastic / NL66%PA+30%GF / Brass / Red copper etc.
This is product it can Improved performance,Increased safety,Versatility etc.
2. specification
| Brand: | YIDE |
| P/N: |
YIDE-519 |
| MOQ: | 500PCS/PER |
| Place of Origin: | Kunshan City,China |
| Delivery Time: | 1 week |
| Start Port: | Shanghai |
| General features: | |
| Product Name |
250A charge and discharge connector |
| Product Spec | 2Pin IP68 Male |
| Connector locking system | Interlock |
| Degree of protection | IP67 |
| Ambient temperature(operation) | -25°C~+85°C |
| Customs tariff number | 8536901900 |
| Environmental compliance | RoHs, Reach |
| Electrical parameters: | |
| Rated voltage | 1000V |
| Rated current(25°C) | 250A |
| Withstand voltage | 500V |
| Contact resistance | ≤10mΩ |
| Insulation resistance | ≥20MΩ |
| Mechanical performance: | |
| Mechanical operation | ≤5000 mating cycles |
| Insertion force | ≤20N |
| Pull out force | ≥3N |
| Wiring range |
0.2m2 -- 13.3m2 |
| Application Area | |
|
Signal & power contal and transmission of E-motorcycle |
|
3. application
E-motorcycle,battery cable,lithium battery connector ETC.
Signal & power contal and transmission of E-motorcycle
Cooperated applicaiton:electric bike ,electric motor,eletric vehicle, new energy car,batter charger etc.
4. advantages
Durable / temperature resistance /freeze-proofing
High current / low resistance
5. more picture
6. company profile
Why Choose Us?
1 Our factory has 10 years experience and strong and professional research and development capabilities.Advanced development and management, comprehensive R&D testing and highly automatic production line make our products high reliability and high performance.
2 Competitive price.
3 Service concept: Making all efforts to offer value-added connector products and services to strengthen client’s competitive advantages.
7. FAQ
Why choose us?
1) Using safer and more environmentally friendly materials
2) Adopt high quality brass, copper, brass lead-free alloy
3) Small resistance, fast current
4) Oxidation resistance, waterproof, high and low temperature resistance
5) More than 10 years of quality assurance for brand manufacturers' direct sales
6) According to product requirements + cable configuration
7) OEM+ ODM
8) After-sales service is guaranteed, 24-hour manual customers online
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
