Custemized E-Motorbike E-Bike E-Vehicle Electrical Plug & Socket
Custemized E-Motorbike E-Bike E-Vehicle Electrical Plug&Socket, Battery Connector
1. product description
Electric motorcycle connectors are used to connect various components of an electric motorcycle, such as the battery, motor, controller, and charging port. These connectors are an essential part of the electric motorcycle system and are crucial for ensuring that the bike operates correctly and efficiently.
1. Directly plug-in docking assembly, simple to use and convenient installation;
2. A special design integrated current and signal transmission in one;
3. The plug with compact structure and dainty apperance, is more suitable for the demand;
4. Innovated and developed in 2011 with independent intellectual property rights;
5. Mainly used for electric Motorcyclemotor cables or battery cables.
2. specification
| Brand: | YIDE |
| P/N: |
YIDE-527 |
| MOQ: | 500PCS/PER |
| Place of Origin: | Kunshan City,China |
| Delivery Time: | 1 week |
| Start Port: | Shanghai |
| General features: | |
| Product Name |
100A 2+7PIN charge connector |
| Product Spec |
2 +7Pin Male |
| Connector locking system | Interlock |
| Degree of protection | IP65 |
| Ambient temperature(operation) | -25°C~+85°C |
| Customs tariff number | 8536901900 |
| Environmental compliance | RoHs, Reach |
| Electrical parameters: | |
| Rated voltage | 96V |
| Rated current(25°C) | 100A |
| Withstand voltage | 500V |
| Contact resistance | ≤10mΩ |
| Insulation resistance | ≥20MΩ |
| Mechanical performance: | |
| Mechanical operation | ≤5000 mating cycles |
| Insertion force | ≤20N |
| Pull out force | ≥3N |
| Wiring range |
0.2m2 -- 10.0m2 |
| Application Area | |
|
Signal & power contal and transmission of E-motorcycle |
|
3. application
E-motorcycle,battery cable,lithium battery connector ETC.
Signal & power contal and transmission of E-motorcycle
4. advantages
IP65 connector.
Cable joint material: PVC, nylon PP, rubber.
You can connect male and female.
We Can provide you with customized solutions.
We Can provide colors and materials, and terminal processing.
Professional R & D team can help customize the project.
