Huawei Hybrid inverter SUN2000-3/4/5/6KTL-L1 single phase solar inverter smart energy controller
Price:
$820.00/pieces 1-9 pieces
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
Huawei
Product Description
Recommend Products
Products Description
SUN2000-6KTL-L1 | 6KW Single Phase |
Datasheet | ||||||
Model Name | SUN2000 -6KTL-L1 | SUN2000-6KTL-L3 | ||||
Input DC | ||||||
Recommended max. PV power | 9000Wp | 7.5kW | 9kW | |||
Max. input voltage | 600V | |||||
Start-up voltage | 200V | |||||
MPPT voltage range | 90V-560V | |||||
Max.current per MPPT | 12.5A | |||||
MPPT number/Max. input strings number | 2 | |||||
Output (AC) | ||||||
Rated output power | 6kW | 5kW | 6kW | |||
Rated output voltage | 220 Vac / 230 Vac / 240 Vac | |||||
Rated grid frequency | 50/60Hz | |||||
Max. output current | 27.3A | 25 A | 27.3 A | |||
Power Factor | 0.8leading - 0.8laging | |||||
THDi | <3% | |||||
Efficiency | ||||||
Max. efficiency | 98.4% | |||||
EU efficiency | 97.8% | |||||
Protection | ||||||
DC reverse-polarity protection | Yes | |||||
Short circuit protection | Yes | |||||
Output over current protection | Yes | |||||
Surge protection | Yes | |||||
Grid monitoring | Yes | |||||
Anti-islanding protection | Yes | |||||
Temperature protection | Yes | |||||
Integrated AFCI (DC arc-fault circuit protection) | Yes | |||||
Integrated DC switch | Yes | |||||
General Data | ||||||
Dimensions (W*H*D) | 365mm * 365mm * 156 mm | |||||
Weight | 12 kg | |||||
Topology | Transformerless | |||||
Self consumption | <5.5W | |||||
Operating temperature range | -25 ~ +60°C | |||||
Relative humidity | 0-100%RH | |||||
Ingress protection | IP65 | |||||
Cooling concept | Natural convection | |||||
Max. operation altitude | 4000m | |||||
Safety Grid Connection Standards | EN 62109-1/-2, IEC 62109-1/-2, EN 50530, IEC 62116, IEC 60068, IEC 61683,IEC 61727, VDE-AR-N4105, VDE 0126-1-1, BDEW, G59/3, UTE C 15-712-1, CEI 0-16, CEI 0-21, RD 661, RD 1699,P.O. 12.3,RD 413, EN-50438-Turkey, EN-50438-Ireland, C10/11, MEA, Resolution No.7,NRS 097-2-1, AS/NZS 4777.2, DEWA | |||||
Features | ||||||
DC Connector | Staubli MC4 | |||||
AC Connector | Waterproof Connector + OT/DT Terminal | |||||
Display | LED Indicators, Integrated WLAN + FusionSolar APP | |||||
Communication | RS485, Optional: Wi-Fi, GPRS | |||||
